System And Components
526-8598 WIPER GP-WINDOW -LOWERS/N GDY1-UP
Group No: 526-8598
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I1163 | 1 BRACKET | 1 | |
| 8T4121 | 2 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4189 | 3 BOLT (M8X1.25X20-MM) | 3 | |
| 1837121 | 4 BOLT (M10X1.5X35-MM) | 2 | |
| 8T4224 | 5 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 9X2044 | 6 SCREW-TRUSS HEAD (M6X1X16-MM) | 2 | |
| 1189901 | 7 SPACER (12X20X10-MM THK) | 2 | |
| 1613128 | 8 RELAY (24-VOLT)(WIPER, LOWER) | 1 | |
| 2041611 | 9 STRAP-CABLE (DUAL) | 1 | |
| 5268602 | 10 ARM AS-WIPER | 1 | |
| 5268603 | 11 BLADE AS-WIPER (LOWER) | 1 | |
| 5268605 | 12 MOTOR GP-WINDOW WIPER | 1 | |
| 5268607 | 13 SUPPORT AS | 1 | |
| 5268577 | LINER | 1 | |
| 9X8256 | 14 WASHER (6.6X12X2-MM THK) | 4 |
