System And Components
487-0240 MOUNTING GP-ENGINE OIL FILTERS/N P6P1-UP
Group No: 487-0240
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3722715 | 1 BRACKET AS | 1 | |
| 5251830 | 2 HOSE AS | 1 | |
| 3722718 | 3 HOSE AS | 1 | |
| 1904885 | 4 SPACER (11X22X50-MM THK) | 1 | |
| 1030892 | 5 GROMMET | 1 | |
| 1984778 | 6 WASHER-HARD (13.5X30X12-MM THK) | 8 | |
| 2270059 | 7 ELBOW | 1 | |
| 2287093 | 8 SEAL-O-RING | 2 | |
| 2154639 | 9 SEAL-O-RING | 1 | |
| 2877301 | 10 VALVE-BALL | 1 | |
| 2Y5829 | 11 NUT (M10X1.5-THD) | 1 | |
| 4J0527 | 12 SEAL-O-RING | 1 | |
| 5P8245 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 6V3823 | 14 BOLT (M12X1.75X60-MM) | 4 | |
| 8T4178 | 15 BOLT (M10X1.5X90-MM) | 1 | |
| 6V5839 | 16 WASHER (11X21X2.5-MM THK) | 2 | |
| 6V6782 | 17 CLIP (SLOT) | 1 | |
| 6V6783 | 18 CLIP (TAB) | 1 | |
| 6V7673 | 19 BOLT (M12X1.75X50-MM) | 4 | |
| 6V8149 | 20 NUT (M12X1.75-THD) | 8 | |
| 6V9008 | 21 ELBOW | 1 | |
| 7M8485 | 22 SEAL-O-RING | 2 | |
| 5P7466 | 23 CLIP (SLOT) | 1 | |
| 5P7467 | 24 CLIP (TAB) | 1 | |
| 5P8112 | 25 GROMMET | 1 |
