System And Components
536-7272 DRIVE GP-FINAL -WITHOUT MOTOR, LHS/N XBJ1-UP; YCP1-UP
Group No: 536-7272
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5661452 | 1 SPACER (8.1X24X5.5-MM THK) | 1 | |
| 5694283 | 2 HOUSING | 1 | |
| 5694284 | 3 COVER | 1 | |
| 5705833 | 4 HUB (LH) | 1 | |
| 5694286 | 5 SHAFT | 1 | |
| 5694287 | 6 GEAR-PLANETARY (35-TEETH) | 4 | |
| 5694288 | 7 GEAR-RING (90-TEETH)(90-TEETH) | 1 | |
| 5694289 | 8 NUT | 1 | |
| 5677160 | 9 SPACER | 1 | |
| 5677161 | 10 SPACER | 4 | |
| 5694290 | 11 PLANETARY AS | 1 | |
| 5694291 | 12 RING-RETAINING | 1 | |
| 4657842 | 13 RING | 4 | |
| 4D6695 | 14 SEAL-O-RING | 1 | |
| 5694292 | 15 SEAL GP-DUO-CONE | 1 | |
| 5694293 | 16 BEARING | 4 | |
| 5677173 | 17 BEARING | 2 | |
| 5677177 | 18 PLUG AS-DRAIN | 1 | |
| 5677180 | 19 PLUG AS-DRAIN | 1 | |
| 3110501 | 20 BOLT (M8X1.25X25-MM) | 8 |
