Assembly
100%

524-8315 LIGHTING GP-FLOOD -VARIABLE ADJUSTABLE BOOMS/N HDT1-UP

Group No: 524-8315
Part NumberPart NameQty
3S20931 STRAP-CABLE4
11601182 CLIP2
48414513 CLIP1
48414564 STRAP-CABLE2
49183435 BRACKET2
52649046 LAMP GP-FLOOD (9-32 VOLT, 850 LM. LED)2
3T0852LOCKNUT (M8X1.25-THD)2
5P4116WASHER-HARD (8.8X20.5X2-MM THK)1
8T6912BOLT (M8X1.25X50-MM)1
52796297 HARNESS AS-LIGHTING1
20416118 STRAP-CABLE (DUAL)6
7I26739 STRAP-CABLE2
8T412110 WASHER-HARD (11X21X2.5-MM THK)6
8T413311 NUT (M10X1.5-THD)2
8T413612 BOLT (M10X1.5X25-MM)4
