System And Components
577-2733 GEAR & BEARING GP-SWINGS/N KTY20001-UP
Group No: 577-2733
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3B8489 | 1 FITTING-GREASE (1/8-27 PTF) | 1 | |
| 5K9243 | 2 ELBOW-FLARED | 2 | |
| 7Y1647 | 3 GASKET | 1 | |
| 1484689 | 4 TUBE AS | 1 | |
| 2276105 | 5 BOOT | 1 | |
| 1459278 | 6 BOLT (M20X2.5X90-MM) | 40 | |
| 5Q3560 | 7 BOLT (M20X2.5X110-MM) | 37 | |
| 4N9170 | 8 CLIP | 2 | |
| 4685306 | 9 SPACER (20.5X38X34-MM THK) | 40 | |
| 4922153 | 10 PLATE AS | 1 | |
| 0964902 | 11 DOWEL | 1 | |
| 1484703 | 12 COVER | 1 | |
| 1484704 | 13 GASKET | 1 | |
| 1719464 | 14 SPACER (20.6X38X6-MM THK) | 37 | |
| 5674399 | 15 GEAR & BEARING GP-SWING | 1 | |
| 7Y1648 | 16 STRIP | 1 | |
| 7Y1650 | 17 CLAMP-HOSE | 1 | |
| 8T4121 | 18 WASHER-HARD (11X21X2.5-MM THK) | 14 | |
| 8T4136 | 19 BOLT (M10X1.5X25-MM) | 12 | |
| 8T4137 | 20 BOLT (M10X1.5X20-MM) | 2 | |
| 8T4199 | 21 BOLT (M8X1.25X12-MM) | 2 | |
| 1U8846 | SEALANT-GASKET |
