System And Components
242-6492 LINES GP-AUXILIARY HYDRAULIC -STICK, MEDIUM PRESSURES/N DHK1-UP; CXY1-UP
Group No: 242-6492
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6C6760 | 1 MANIFOLD | 2 | |
| 1491738 | 2 CLIP | 4 | |
| 1879977 | 3 PLATE | 2 | |
| 1879978 | 4 SUPPORT AS | 1 | |
| 1879981 | 5 SUPPORT AS | 1 | |
| 3827079 | 6 HOSE AS | 2 | |
| 2501440 | 7 ADAPTER AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 7X3164 | ADAPTER-SWIVEL | 1 | |
| 2536685 | 8 TUBE AS | 2 | |
| 6V8398 | 9 SEAL-O-RING | 4 | |
| 8T4121 | 10 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4136 | 11 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4139 | 12 BOLT (M12X1.75X30-MM) | 8 | |
| 8T4223 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 8 | |
| 8T4185 | 14 BOLT (M10X1.5X50-MM) | 4 | |
| 1972362 | 15 PLATE | 2 | |
| 7X2543 | 16 BOLT (M10X1.5X120-MM) | 4 | |
| 8T4183 | 17 BOLT (M12X1.75X40-MM) | 8 |
