System And Components
430-8419 WIRING GP-HEATERS/N RAD1-895; WRN1-535; WES1-383
Group No: 430-8419
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3E5239 | 1 RELAY AS (24-VOLT)(HEATER, AIR CONDITIONER) | 2 | |
| 4696692 | 2 GROMMET | 1 | |
| 4212868 | 3 RECEPTACLE AS | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 12 | |
| 4488733 | 4 HARNESS AS-HEATER & AIR COND | 1 | |
| 1325789 | 5 CLIP (LADDER) | 2 | |
| 1566175 | 6 CLIP (LADDER) | 1 | |
| 3812621 | 7 MOUNTING-CABLE TIE | 1 | |
| 5C2890 | 8 NUT (M6X1-THD) | 1 | |
| 7K1181 | 9 STRAP-CABLE | 12 | |
| 8T4121 | 10 WASHER-HARD (11X21X2.5-MM THK) | 2 | |
| 8T4133 | 11 NUT (M10X1.5-THD) | 1 | |
| 8T4138 | 12 BOLT (M6X1X20-MM) | 1 | |
| 8T4196 | 13 BOLT (M10X1.5X35-MM) | 1 | |
| 8T4205 | 14 WASHER-HARD (7.2X14.5X2-MM THK) | 2 |
