System And Components
466-1465 LINES GP-AIR STARTING (CHG -00 THRU -05)
Group No: 466-1465
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2V5956 | 1 HOSE AS | 1 | |
| 3E2319 | 2 VALVE-BALL (AIR STARTING) | 1 | |
| 3J7355 | 3 UNION-FLARED | 1 | |
| 3N7281 | 4 HOSE AS | 1 | |
| 3V6153 | 5 HOSE AS | 1 | |
| 5G3699 | 6 HOSE AS | 1 | |
| 5N7131 | 7 FLANGE | 1 | |
| 6L7028 | 8 JOINT AS | 1 | |
| 9X7535 | SEAL | 2 | |
| 7C0370 | 9 TUBE AS | 1 | |
| 7C0371 | 10 TUBE AS | 1 | |
| 7C0372 | 11 BRACKET | 2 | |
| 7D4754 | 12 BUSHING | 1 | |
| 8N8471 | 13 CLAMP-TUBE | 2 | |
| 8Q9642 | 14 ELBOW | 1 | |
| 0332177 | 15 TEE-PIPE | 1 | |
| 1339637 | 16 BRACKET | 1 | |
| 1387205 | 17 CLAMP-PIPE | 2 | |
| 1893269 | 18 HOSE AS | 1 | |
| 2163020 | 19 HOSE AS | 1 | |
| 2343544 | 20 SEAL-O-RING | 1 | |
| 2461245 | 21 FITTING | 1 | |
| 2680161 | 22 HOSE AS | 1 | |
| 2794506 | 23 FITTING | 1 | |
| 3215582 | 24 HOSE AS | 1 | |
| 3282203 | 25 BRACKET AS | 1 | |
| 3490734 | 26 CROSS-PIPE | 1 | |
| 3554516 | 27 PIPE | 2 | |
| 0307946 | 28 ELBOW | 2 | |
| 0520572 | 29 TEE-SWIVEL | 1 | |
| 0676495 | 30 ELBOW-FLARED | 1 | |
| 0S1587 | 31 BOLT (1/2-13X1.75-IN) | 8 | |
| 0S1588 | 32 BOLT (3/8-16X1.25-IN) | 1 | |
| 0S1594 | 33 BOLT (3/8-16X1-IN) | 2 | |
| 0S1619 | 34 BOLT (3/8-16X3-IN) | 3 | |
| 1P4579 | 35 FLANGE-HALF | 2 | |
| 2147566 | 36 SEAL-O-RING | 2 | |
| 3E9865 | 37 LOCKNUT (1/4-20-THD) | 4 | |
| 3V3308 | 38 WASHER-HARD (10.2X20.5X2.5-MM THK) | 7 | |
| 4L3776 | 39 BOLT (1/4-20X4.75-IN) | 4 | |
| 4S6399 | 40 CONNECTOR | 4 | |
| 5B7660 | 41 BUSHING-REDUCER | 2 | |
| 5P0537 | 42 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 5P8245 | 43 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 6B6205 | 44 SPACER (0.438X0.875X1.281-IN THK) | 4 | |
| 6D3479 | 45 CLIP (LOOP)(LOOP) | 2 | |
| 6K1972 | 46 ELBOW-FLARED | 3 | |
| 7K6462 | 47 ELBOW | 2 | |
| 7K9197 | 48 ELBOW | 3 | |
| 8N8451 | 49 GASKET | 1 | |
| 8Q9643 | 50 FITTING | 1 | |
| 9S8752 | 51 NUT-FULL (3/8-16-THD) | 1 | |
| 2B0947 | 52 BOLT (1/2-13X2.25-IN) | 2 |
