System And Components
6N-5011 FILTER GP-ENGINE OILDUPLEX RH
Group No: 6N-5011
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N1936 | 1 HOSE AS (.25M) | 1 | |
| 3S1099 | ELBOW-FLARED | 1 | |
| 6N4207 | 2 BRACKET | 1 | |
| 5S7348 | 3 SCREW-MACHINE (6-32X0.375-IN) | 2 | |
| 4B2041 | NUT (6-32-THD) | 2 | |
| 9B1117 | LOCKWASHER | 2 | |
| 2W3681 | 4 INDICATOR AS (ENGINE OIL PRESSURE) | 2 | |
| 6V3507 | SEAL-RECTANGULAR | 2 | |
| 2N0794 | RETAINER | 2 | |
| 2N0178 | 5 PANEL (FRONT) | 1 | |
| 2N0179 | COVER-PANEL (REAR) | 1 | |
| 1L6561 | 6 PLUG | 1 | |
| 6N3170 | 7 HOSE AS (.51M) | 1 | |
| 8B4884 | ELBOW | 1 | |
| 2N5848 | 8 BASE AS | 1 | |
| 7H4155 | MOUNT-FLEXIBLE | 3 | |
| 2N2258 | RIVET-POP | 6 | |
| 9F6580 | 9 BOLT (1/4-20X1.125-IN) | 3 | |
| 1B4330 | NUT (1/4-20-THD) | 3 | |
| 5P0537 | WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 0S1594 | 10 BOLT (3/8-16X1-IN) | 4 | |
| 1D4717 | 11 NUT (3/8-16-THD) | 9 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 16 | |
| 1A5183 | 12 BOLT (3/8-16X4.75-IN) | 1 | |
| 1A5964 | BOLT (3/8-16X4.5-IN) | 1 | |
| 6N7423 | 13 COVER AS | 1 | |
| 1L6939 | 14 ELBOW | 4 | |
| 5P6923 | 15 ADAPTER | 2 | |
| 9L5125 | 16 ELBOW | 1 | |
| 0S1571 | 17 BOLT (3/8-16X1.75-IN) | 8 | |
| 2P4305 | 18 GASKET | 2 | |
| 7B9919 | 19 CLIP | 1 | |
| 8S8817 | GROMMET | 1 | |
| 1W6358 | 20 TUBE AS | 1 | |
| 4N0790 | 21 GASKET | 1 | |
| 6N8183 | 22 ADAPTER | 1 | |
| 8M5260 | SEAL-O-RING | 1 | |
| 2W0002 | 23 TUBE AS | 1 | |
| 0S1608 | 24 BOLT (3/8-16X3.75-IN) | 2 | |
| 8M9024 | 25 WASHER-HARD (10.2X22.5X5-MM THK) | 4 | |
| 6N3895 | 26 PLATE | 1 | |
| 9S7720 | 27 ELBOW-FLARED | 1 | |
| 6N7422 | 28 COVER AS | 1 | |
| 0L1351 | 29 BOLT (3/8-16X0.875-IN) | 1 | |
| 9M0766 | 30 BRACKET | 1 | |
| 6N5010 | 31 TUBE AS | 1 | |
| 5K9979 | 32 CONNECTOR | 1 | |
| 7K1457 | 33 CONNECTOR | 2 | |
| 8F8513 | 34 CLIP (LOOP) | 3 | |
| 9F2940 | 35 GROMMET | 3 | |
| 8L5008 | 36 ELBOW-PIPE | 1 | |
| 6N0824 | 37 GASKET | 1 | |
| 6N1258 | 38 HOUSING | 1 | |
| 7N0912 | 39 VALVE GP-FLUID CONTROL (ENGINE OIL) | 1 | |
| 3F9190 | 40 PIN | 1 | |
| 1B8704 | 41 KEY-WOODRUFF | 2 | |
| 7N0914 | 42 DETENT AS | 1 | |
| 6N4205 | PLATE | 1 | |
| 6N4204 | 43 PIN | 2 | |
| 8F8833 | 44 PIN | 1 | |
| 7N0913 | 45 RING | 1 | |
| 6J8356 | 46 SPRING | 2 | |
| 8H1607 | 47 SEAL-O-RING | 1 | |
| 2P4305 | 48 GASKET | 4 | |
| 0S1571 | 49 BOLT (3/8-16X1.75-IN) | 7 | |
| 2P4303 | 50 BASE AS-OIL FILTER | 1 | |
| 2P4304 | STUD-HOLLOW | 1 | |
| 1D4717 | 51 NUT (3/8-16-THD) | 7 | |
| 5M2894 | 52 WASHER-HARD (10.2X18.5X2.5-MM THK) | 18 | |
| 2P4301 | 53 BASE AS-OIL FILTER | 1 | |
| 2P4304 | STUD-HOLLOW | 1 | |
| 1A2029 | 54 BOLT (3/8-16X1.125-IN) | 1 | |
| 2P3761 | 55 COVER | 1 | |
| 2P3760 | GASKET | 1 | |
| 0S1594 | 56 BOLT (3/8-16X1-IN) | 3 | |
| 4H9756 | 57 LEVER-RELEASE CONTROL | 1 | |
| 6N1260 | 58 PLATE | 1 | |
| 2M1538 | 59 STUD-TAPERLOCK (3/8-16X1.6-IN) | 8 | |
| 8N7043 | 60 FILM (OIL FILTER DUPLEX VALVE)(INSTRUCTION) | 1 | |
| 5B2638 | 61 BOLT (3/8-16X5.25-IN) | 2 | |
| 6N1259 | 62 POINTER | 1 | |
| 4N8150 | 63 SPRING | 1 | |
| 1P1367 | 64 PLUNGER (RELIEF VALVE) | 1 | |
| 2P4005 | 65 FILTER AS-ENGINE OIL | 2 | |
| 4N7082 | 66 SHIELD-OIL FILTER | 2 | |
| 7F9090 | 67 SCREW-DRIVE (NO 8X3/8-IN) | 4 | |
| 1L6561 | PLUG | 1 | |
| 6D3479 | CLIP (LOOP) | 1 |
