System And Components
6N-5011 FILTER GP-ENGINE OILDUPLEX RH
Group No: 6N-5011
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1B4330 | 1 NUT (1/4-20-THD) | 3 | |
| 1B8704 | 2 KEY-WOODRUFF | 2 | |
| 9S8752 | 3 NUT-FULL (3/8-16-THD) | 16 | |
| 1L6939 | 4 ELBOW | 3 | |
| 1R1808 | 5 FILTER-ENGINE OIL (ADVANCED EFFICIENCY) | 2 | |
| 2N0178 | 6 PANEL | 1 | |
| 2N0179 | 7 COVER-PANEL | 1 | |
| 2N5848 | 8 BASE AS | 1 | |
| 2P3760 | 9 GASKET | 1 | |
| 2P3761 | 10 COVER | 1 | |
| 2P4301 | 11 BASE AS-OIL FILTER | 1 | |
| 2P4304 | STUD-HOLLOW | 1 | |
| 2P4303 | 12 BASE AS-OIL FILTER | 1 | |
| 2P4304 | STUD-HOLLOW | 1 | |
| 2P4305 | 13 GASKET | 6 | |
| 2W0002 | 14 TUBE AS | 1 | |
| 2W3681 | 15 INDICATOR AS (ENGINE OIL PRESSURE) | 2 | |
| 4H9756 | 16 LEVER-RELEASE CONTROL | 1 | |
| 4N7082 | 17 SHIELD-OIL FILTER | 2 | |
| 4N8150 | 18 SPRING | 1 | |
| 4W9600 | 19 TUBE AS | 1 | |
| 5K9979 | 20 CONNECTOR | 1 | |
| 5P6923 | 21 ADAPTER | 2 | |
| 6N0824 | 23 GASKET | 1 | |
| 6N1258 | 24 HOUSING | 1 | |
| 6N1259 | 25 POINTER | 1 | |
| 6N1260 | 26 PLATE | 1 | |
| 6N1936 | 27 HOSE AS | 1 | |
| 6N3170 | 28 HOSE AS | 1 | |
| 6N3895 | 29 PLATE | 1 | |
| 6N4207 | 30 BRACKET | 1 | |
| 6N5010 | 31 TUBE AS | 1 | |
| 6N7422 | 32 COVER AS | 1 | |
| 6N7423 | 33 COVER AS | 1 | |
| 6N8183 | 34 ADAPTER | 1 | |
| 7K1457 | 35 CONNECTOR | 1 | |
| 7N0912 | 36 VALVE GP-FLUID CONTROL (ENGINE OIL) | 1 | |
| 7N0911 | VALVE AS | 1 | |
| 3F9190 | PIN | 1 | |
| 7N0914 | 37 DETENT AS | 1 | |
| 6N4205 | PLATE | 1 | |
| 6N4204 | PIN | 2 | |
| 8F8833 | PIN | 1 | |
| 7N0913 | RING | 1 | |
| 6J8356 | SPRING | 2 | |
| 7W2731 | 38 RETAINER | 2 | |
| 8S8817 | 39 GROMMET | 1 | |
| 9F2940 | 40 GROMMET | 3 | |
| 9M0766 | 41 BRACKET | 1 | |
| 9M0853 | 42 PLUNGER-VALVE | 1 | |
| 9S7720 | 43 ELBOW-FLARED | 1 | |
| 0323237 | 44 SPACER (10.93X19.05X25.4-MM THK) | 1 | |
| 2395572 | 45 SEAL-INTEGRAL | 1 | |
| 0L1351 | 46 BOLT (3/8-16X0.875-IN) | 1 | |
| 0S1571 | 47 BOLT (3/8-16X1.75-IN) | 15 | |
| 0S1594 | 48 BOLT (3/8-16X1-IN) | 7 | |
| 1A2029 | 49 BOLT (3/8-16X1.125-IN) | 1 | |
| 1A5183 | 50 BOLT (3/8-16X4.75-IN) | 1 | |
| 1A5964 | 51 BOLT (3/8-16X4.5-IN) | 1 | |
| 1L6561 | 52 PLUG | 2 | |
| 3S1099 | 53 ELBOW-FLARED | 1 | |
| 4B2041 | 54 NUT (6-32-THD) | 2 | |
| 5B2638 | 55 BOLT (3/8-16X5.25-IN) | 2 | |
| 5M2894 | 56 WASHER-HARD (10.2X18.5X2.5-MM THK) | 36 | |
| 5P0537 | 57 WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 5S7348 | 58 SCREW-MACHINE (6-32X0.375-IN) | 2 | |
| 6D3479 | 59 CLIP (LOOP) | 1 | |
| 6V3507 | 60 SEAL-RECTANGULAR | 2 | |
| 7F9090 | 61 SCREW-DRIVE (NO 8X3/8-IN) | 4 | |
| 7H7055 | 62 CLIP | 1 | |
| 8B4884 | 63 ELBOW | 1 | |
| 8F8513 | 64 CLIP (LOOP) | 3 | |
| 8H1607 | 65 SEAL-O-RING | 1 | |
| 8L5008 | 66 ELBOW-PIPE | 1 | |
| 8M1047 | 67 STUD-TAPERLOCK (3/8-16X1.67-IN) | 8 | |
| 8M5260 | 68 SEAL-O-RING | 1 | |
| 8M9024 | 69 WASHER-HARD (10.2X22.5X5-MM THK) | 4 | |
| 8S9191 | 70 BOLT (3/8-16X4-IN) | 2 | |
| 9B1117 | 71 LOCKWASHER | 2 | |
| 9F6580 | 72 BOLT (1/4-20X1.125-IN) | 3 | |
| 9L5125 | 73 ELBOW | 1 |
