System And Components
6N-5217 LINES GP-ENGINE OILLH MOUNTED DUPLEX FILTERS
Group No: 6N-5217
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 6N4114 | 1 BRACKET | 1 | |
| 0S1594 | 2 BOLT (3/8-16X1-IN) | 7 | |
| 5M2894 | 3 WASHER-HARD (10.2X18.5X2.5-MM THK) | 26 | |
| 4N1683 | 4 COVER | 1 | |
| 4N1684 | GASKET | 1 | |
| 8M9024 | 5 WASHER-HARD (10.2X22.5X5-MM THK) | 8 | |
| 5P6923 | 6 ADAPTER | 2 | |
| 1L6939 | ELBOW | 2 | |
| 6N7422 | 7 COVER AS | 1 | |
| 0S1571 | 8 BOLT (3/8-16X1.75-IN) | 14 | |
| 2P4301 | 9 BASE AS-OIL FILTER (OIL FILTER) | 1 | |
| 2P4304 | STUD-HOLLOW | 1 | |
| 2P3761 | 10 COVER | 1 | |
| 2P3760 | GASKET | 1 | |
| 0S1588 | 11 BOLT (3/8-16X1.25-IN) | 4 | |
| 2P4305 | 12 GASKET | 4 | |
| 2P4303 | 13 BASE AS-OIL FILTER | 1 | |
| 2P4304 | STUD-HOLLOW | 1 | |
| 6N7420 | 14 COVER AS | 1 | |
| 6N4102 | 15 BRACKET | 1 | |
| 1W6360 | 16 TUBE AS | 1 | |
| 7K1457 | 17 CONNECTOR | 2 | |
| 5L1719 | 18 STUD-TAPERLOCK | 2 | |
| 1A2029 | 19 BOLT (3/8-16X1.125-IN) | 1 | |
| 2P4005 | 20 FILTER AS-ENGINE OIL | 2 | |
| 6K3886 | 21 CLIP | 3 | |
| 9F2940 | 22 GROMMET | 3 | |
| 1W6361 | 23 TUBE AS | 1 | |
| 5L2727 | 24 SEAL-O-RING | 2 | |
| 4N7082 | 25 SHIELD-OIL FILTER | 2 | |
| 7F9090 | SCREW-DRIVE (NO 8X3/8-IN) | 4 | |
| 1P1367 | 26 PLUNGER (RELIEF VALVE) | 1 | |
| 4N8150 | SPRING | 1 | |
| 6N4474 | 27 TUBE AS | 1 | |
| 0T0102 | 28 BOLT (3/8-16X0.625-IN) | 2 | |
| 4B5271 | WASHER (25.5X11.2X2-MM THK) | 2 | |
| 0L1143 | 29 BOLT (3/8-16X2.5-IN) | 2 | |
| 6N3732 | 30 ELBOW | 1 | |
| 4N0933 | GASKET | 1 | |
| 0L0765 | 31 STUD (3/8-16X1.75-IN) | 1 | |
| 0S1591 | 32 BOLT (3/8-16X1.5-IN) | 2 | |
| 1D4717 | 33 NUT (3/8-16-THD) | 10 | |
| 3N4411 | 34 HOSE AS | 2 | |
| 5S7348 | 35 SCREW-MACHINE (6-32X0.375-IN) | 2 | |
| 4B2041 | NUT (6-32-THD) | 2 | |
| 9B1117 | LOCKWASHER | 2 | |
| 2N2414 | 36 GAUGE-OIL PRESSURE (ENGINE) | 2 | |
| 2N0794 | RETAINER | 2 | |
| 8B4884 | ELBOW | 2 | |
| 1L6561 | 37 PLUG | 2 | |
| 0S1594 | 38 BOLT (3/8-16X1-IN) | 5 | |
| 1D4717 | 39 NUT (3/8-16-THD) | 6 | |
| 5M2894 | 40 WASHER-HARD (10.2X18.5X2.5-MM THK) | 11 | |
| 2N0178 | 41 PANEL (FRONT) | 1 | |
| 2N0179 | COVER-PANEL (REAR) | 1 | |
| 2N5848 | 42 BASE AS | 1 | |
| 9F6580 | 43 BOLT (1/4-20X1.125-IN) | 3 | |
| 1B4330 | NUT (1/4-20-THD) | 3 | |
| 5P0537 | WASHER-HARD (7.2X14.5X2-MM THK) | 3 | |
| 6N4444 | 44 BRACKET | 1 | |
| 2P4305 | 45 GASKET | 2 | |
| 2N1287 | 46 ELBOW-FLARED | 2 | |
| 6N0816 | 47 FILM-DUPLEX VALVE | 1 | |
| 5B2638 | 48 BOLT (3/8-16X5.25-IN) | 2 | |
| 5L5709 | 49 CONNECTOR-SHIELD | 1 | |
| 6N4470 | 50 TUBE AS | 1 | |
| 0T0573 | 51 BOLT (3/8-16X2.75-IN) | 4 | |
| 4N0790 | 52 GASKET | 2 | |
| 5L2727 | 53 SEAL-O-RING | 4 | |
| 6N4481 | 54 FLANGE | 2 | |
| 7N0914 | 55 DETENT AS | 1 | |
| 6N4205 | PLATE | 1 | |
| 6J8356 | SPRING | 2 | |
| 6N4204 | 56 PIN | 2 | |
| 8F8833 | 57 PIN | 1 | |
| 7N0913 | 58 RING | 1 | |
| 1B8704 | 59 KEY-WOODRUFF | 2 | |
| 6N0824 | 60 GASKET | 1 | |
| 6N1258 | 61 HOUSING | 1 | |
| 7N0912 | 62 VALVE GP-FLUID CONTROL (ENGINE OIL FILTER) | 1 | |
| 3F9190 | 63 PIN | 1 | |
| 8H1607 | 64 SEAL-O-RING | 1 | |
| 6N4472 | 65 TUBE AS | 1 | |
| 6N3732 | 66 ELBOW | 1 | |
| 4N0933 | 67 GASKET | 1 | |
| 0L1143 | 68 BOLT (3/8-16X2.5-IN) | 1 | |
| 6N1259 | 69 POINTER | 1 | |
| 0S1571 | 70 BOLT (3/8-16X1.75-IN) | 1 | |
| 2M1538 | 71 STUD-TAPERLOCK (3/8-16X1.6-IN) | 8 | |
| 6N1260 | 72 PLATE | 1 | |
| 4H9756 | 73 LEVER-RELEASE CONTROL | 1 | |
| 6D3479 | 74 CLIP (LOOP) | 1 | |
| 9L8925 | BOLT (5/16-18X1.25-IN) | 1 |
