System And Components
4W-9540 PANEL GP-INSTRUMENT24 V
Group No: 4W-9540
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 9W1491 | 1 KIT-SERVICE METER | 1 | |
| 6L2845 | 2 BRACKET-MOUNTING | 1 | |
| 2N0821 | 3 COVER-PANEL | 1 | |
| 7L4536 | 4 BRACKET-TACHOMETER | 1 | |
| 5N9035 | 5 TACHOMETER GP-ELECTRIC | 1 | |
| 5L7444 | 6 INDICATOR (WATER TEMPERATURE) | 1 | |
| 6V3507 | 7 SEAL-RECTANGULAR | 3 | |
| 2N0794 | RETAINER | 3 | |
| 3B6769 | 8 ELBOW | 1 | |
| 2W3687 | 9 INDICATOR-FUEL PRESSURE | 1 | |
| 2N5848 | 10 BASE AS | 1 | |
| 3N4622 | 11 HOSE AS | 1 | |
| 0307941 | 12 ELBOW | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 0302010 | 13 SENDER AS-PRESSURE (OIL) | 1 | |
| 4M5317 | 14 BUSHING-REDUCER | 1 | |
| 5L7442 | 15 SENDING UNIT (24-VOLT) | 1 | |
| 6N0360 | 16 WIRE AS | 1 | |
| 9F6580 | 17 BOLT (1/4-20X1.125-IN) | 3 | |
| 1B4330 | NUT (1/4-20-THD) | 3 | |
| 5P0537 | WASHER-HARD (7.2X14.5X2-MM THK) | 6 | |
| 0S1591 | 18 BOLT (3/8-16X1.5-IN) | 2 | |
| 1D4717 | NUT (3/8-16-THD) | 2 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 2Y5575 | 19 SPACER (10X15.8X11.6-MM THK) | 2 | |
| 6N0359 | 20 WIRE AS | 1 | |
| 2N0816 | 21 PANEL-INSTRUMENT | 1 | |
| 5S7348 | 22 SCREW-MACHINE (6-32X0.375-IN) | 2 | |
| 4B2041 | NUT (6-32-THD) | 2 | |
| 6V9499 | WASHER-HARD (4.3X7X0.8-MM THK) | 2 | |
| 1W7143 | 23 INDICATOR-PRESSURE | 1 | |
| 2H3755 | 24 BOLT (5/16-18X0.43-IN) | 4 | |
| 1D4716 | NUT-FULL (5/16-18-THD) | 4 | |
| 9M1974 | WASHER-HARD (8.8X16X2-MM THK) | 8 | |
| 1F7307 | 25 AMMETER GP | 1 | |
| 6V3507 | SEAL-RECTANGULAR | 1 |
