System And Components
2N-2259 PANEL GP-INSTRUMENTType 2
Group No: 2N-2259
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5S7348 | 1 SCREW-MACHINE (6-32X0.375-IN) | 2 | |
| 4B2041 | 2 NUT (6-32-THD) | 2 | |
| 1L6561 | 3 PLUG | 1 | |
| 2W3681 | 4 INDICATOR AS (ENGINE OIL PRESSURE) | 1 | |
| 2005220 | 5 GAUGE GP-COOLANT TEMPERATURE (WATER) | 1 | |
| 3L2875 | 6 CLIP | 1 | |
| 8F0244 | 7 GROMMET | 1 | |
| 2N0178 | 8 PANEL | 1 | |
| 7W2731 | 9 RETAINER | 2 | |
| 3B6487 | 10 COUPLING (PIPE) | 1 | |
| 2N0179 | 11 COVER-PANEL | 1 | |
| 2N1287 | 12 ELBOW-FLARED | 1 | |
| 3P6048 | 13 HOSE AS | 1 | |
| 2143613 | 14 ADAPTER | 1 | |
| 8B2664 | 15 BUSHING-REDUCER | 1 | |
| 2N5848 | 16 BASE AS | 1 | |
| 2H3755 | 17 BOLT (5/16-18X0.43-IN) | 2 | |
| 9M1974 | 18 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 4B4277 | 19 WASHER (8.8X17.5X1.6-MM THK) | 2 | |
| 9F6580 | 20 BOLT (1/4-20X1.125-IN) | 3 | |
| 9S8750 | 21 NUT-FULL (1/4-20-THD) | 3 | |
| 2D7325 | 22 TEE-PIPE | 1 | |
| 4S6399 | 23 CONNECTOR | 1 | |
| 4K8864 | 24 CLIP (LOOP) | 1 | |
| 5M6213 | 25 PLUG-PIPE (1/4-18-THD) | 1 | |
| 6V3507 | 26 SEAL-RECTANGULAR | 2 |
