System And Components
3N-6642 PANEL GP-INSTRUMENT24 OR 32 VOLT. SINGLE--ELECTRICAL
Group No: 3N-6642
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7W2060 | 1 GAUGE (WATER TEMPERATURE) | 1 | |
| 2W5111 | 2 AMMETER AS | 1 | |
| 1977347 | 3 TACHOMETER GP-ELECTRIC | 1 | |
| 6V8377 | NUT (8-32-THD) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 7W2937 | 4 GAUGE GP-ENGINE OIL PRESSURE | 1 | |
| 7W3035 | 5 INDICATOR (GEAR OIL PRESSURE) | 1 | |
| 6V3507 | SEAL-RECTANGULAR | 1 | |
| 5L7438 | 6 PLATE-FACE | 1 | |
| 5L7439 | 7 FRAME AS | 1 | |
| 5L7437 | 8 SOCKET & WIRE (LIGHT) | 4 | |
| 5D0019 | 9 LAMP (24-VOLT) | 2 | |
| 9X1124 | 10 SENDER AS-PRESSURE (ENGINE OIL PRESSURE) | 1 | |
| 4B2049 | NUT (10-32-THD) | 1 | |
| 8F1434 | LOCKWASHER | 1 | |
| 8T0328 | WASHER-HARD (5.5X10X1-MM THK) | 1 | |
| 5L7442 | 11 SENDING UNIT (24-VOLT) | 1 | |
| 5P3422 | 12 TEE-PIPE | 1 | |
| 7W2118 | 13 SENDER-PRESSURE (GEAR OIL PRESSURE) | 1 | |
| 5L7441 | 14 RESISTOR UNIT (65-OHM, 32-VOLT) | 3 | |
| 5L7447 | 15 SHUNT (AMMETER) (.003 OHMS) | 1 | |
| 6B5072 | 16 ADAPTER (LARGE) | 1 | |
| 4M5317 | 17 BUSHING-REDUCER (SMALL) | 2 | |
| 2D7325 | 18 TEE-PIPE | 2 | |
| 2L3402 | 19 SWITCH AS (PRESSURE)(ENGINE OIL) | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 1645524 | 20 GENERATOR-SIGNAL | 1 | |
| 5N8209 | 24 HARNESS AS-WIRING (TACHOMETER) | 1 | |
| 5P5677 | WIRE (18-GA, BLACK) | ||
| 7N9017 | TERMINAL-RING (18-GA TO 22-GA, NO. 10 SCREW) | 2 | |
| 7N9737 | HOUSING-RECEPTACLE (14-GA TO 18-GA) | 1 | |
| 7N7780 | PIN-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7N7779 | SOCKET-CONNECTOR (14-GA TO 18-GA) | 1 | |
| 7W2731 | 25 RETAINER | 1 | |
| 6V3507 | 26 SEAL-RECTANGULAR | 1 | |
| 8T9825 | 27 WIRE AS | 1 | |
| 7T8275 | 28 SHAFT-MAIN DRIVE | 1 | |
| 1552274 | 29 KIT-CONNECTING PLUG (6-PIN) | 1 | |
| 1863736 | 30 SOCKET-CONNECTOR (16-GA TO 18-GA) | 4 |
