System And Components
8N-2586 PANEL GP-INSTRUMENT -RHFOR USE WITH ENGINES BUILT WITH TOP MOUNTED TURBOCHARGER
Group No: 8N-2586
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5P3422 | 1 TEE-PIPE | 1 | |
| 6V3507 | 2 SEAL-RECTANGULAR | 2 | |
| 6K8179 | 3 CLIP | 1 | |
| 4L6459 | 4 BOLT (3/8-16X2.5-IN) | 3 | |
| 8L6557 | 5 CONNECTOR | 1 | |
| 3S2093 | 6 STRAP-CABLE | 5 | |
| 5S7348 | 7 SCREW-MACHINE (6-32X0.375-IN) | 2 | |
| 4B2041 | 8 NUT (6-32-THD) | 2 | |
| 1L6561 | 9 PLUG | 1 | |
| 2W3681 | 10 INDICATOR AS (ENGINE OIL PRESSURE) | 1 | |
| 2005222 | 11 GAUGE GP-COOLANT TEMPERATURE (WATER) | 1 | |
| 4B2049 | NUT (10-32-THD) | 2 | |
| 8F1434 | LOCKWASHER | 2 | |
| 3B8822 | 13 ELBOW | 1 | |
| 2N0178 | 14 PANEL | 1 | |
| 7W2731 | 15 RETAINER | 2 | |
| 2N0179 | 16 COVER-PANEL | 1 | |
| 2L6094 | 17 ELBOW | 1 | |
| 5C5881 | 18 HOSE AS | 1 | |
| 8T4896 | 19 WASHER-HARD (10.2X18.5X2.5-MM THK) | 1 | |
| 8T4896 | 20 WASHER-HARD (10.2X18.5X2.5-MM THK) | 3 | |
| 8N2584 | 21 BRACKET AS | 1 | |
| 8T6764 | 22 PLUG-PIPE (1/8-27-THD) | 1 | |
| 6D2928 | 23 BOLT (1/4-20X1.125-IN) | 3 | |
| 6V8185 | 24 NUT (1/4-20-THD) | 3 | |
| 6H6699 | 25 ADAPTER (HEAT INDICATOR) | 1 | |
| 8B2664 | 26 BUSHING-REDUCER | 1 | |
| 4L6454 | 27 BOLT (3/8-16X1-IN) | 2 | |
| 8T4896 | 28 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 6V8001 | 29 SEAL-O-RING | 2 | |
| 2N5848 | 30 BASE AS | 1 |
