System And Components
8N-2586 PANEL GP-INSTRUMENTFOR USE WITH ENGINES BUILT WITH TOP MOUNTED TURBOCHARGER
Group No: 8N-2586
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5S7348 | 1 SCREW-MACHINE (6-32X0.375-IN) | 2 | |
| 4B2041 | NUT (6-32-THD) | 2 | |
| 1L6561 | 2 PLUG | 1 | |
| 2W3681 | 3 INDICATOR AS (ENGINE OIL PRESSURE) | 1 | |
| 2L6094 | 4 ELBOW | 1 | |
| 2N0794 | 5 RETAINER | 2 | |
| 2W3670 | 6 INDICATOR (ENGINE COOLANT TEMPERATURE) | 1 | |
| 2N0178 | 7 PANEL | 1 | |
| 2N0179 | 8 COVER-PANEL | 1 | |
| 2N5848 | 9 BASE AS | 1 | |
| 9F6580 | 10 BOLT (1/4-20X1.125-IN) | 3 | |
| 1B4330 | NUT (1/4-20-THD) | 3 | |
| 0S1594 | 11 BOLT (3/8-16X1-IN) | 2 | |
| 1D4717 | NUT (3/8-16-THD) | 2 | |
| 8N2584 | 12 BRACKET AS | 1 | |
| 6H6699 | 13 ADAPTER (HEAT INDICATOR) | 1 | |
| 8B2664 | 14 BUSHING-REDUCER | 1 | |
| 5C5881 | 15 HOSE AS | 1 | |
| 8L6557 | 16 CONNECTOR | 1 | |
| 5P3422 | 17 TEE-PIPE | 1 | |
| 3B8822 | ELBOW | 1 | |
| 5M6214 | 18 PLUG (1/8-27 PTF) | 1 | |
| 6K8179 | 19 CLIP | 1 | |
| 6V3507 | 20 SEAL-RECTANGULAR | 2 | |
| 0L1143 | 21 BOLT (3/8-16X2.5-IN) | 3 | |
| 5M2894 | 22 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 3S2093 | 23 STRAP-CABLE | 5 | |
| 5M2894 | 24 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 |
