System And Components
8N-8490 CONTROL GP-AIR STARTING115-VOLT AC
Group No: 8N-8490
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5J7303 | 1 ELBOW (45-DEGREE) | 1 | |
| 6K1972 | ELBOW-FLARED (90-DEGREE) | 1 | |
| 5N2746 | 2 VALVE-SOLENOID | 1 | |
| 6N9587 | 3 CONNECTOR | 2 | |
| 5P5610 | 4 CONNECTOR | 2 | |
| 3B7275 | 5 NIPPLE-PIPE | 1 | |
| 3N4579 | 6 HOSE AS | 1 | |
| 3F2065 | 7 LOCKNUT (1/2-14-THD) | 1 | |
| 4F8184 | 8 BUSHING-TERMINAL | 1 | |
| 3N2419 | 9 SWITCH (START) | 1 | |
| 0S1591 | 10 BOLT (3/8-16X1.5-IN) | 2 | |
| 1D4717 | NUT (3/8-16-THD) | 2 | |
| 5M2894 | WASHER-HARD (10.2X18.5X2.5-MM THK) | 2 | |
| 5P1075 | WASHER-HARD (10.2X22.5X3-MM THK) | 2 | |
| 8N2262 | 11 PLATE-CONTROL MOUNTING | 1 | |
| 4B1233 | 12 SCREW (10-24X0.875-IN) | 2 | |
| 4B2047 | NUT (10-24-THD) | 2 | |
| 3B4502 | LOCKWASHER | 2 | |
| 5L2579 | 13 GROMMET | 1 |
