System And Components
7W-9745 LINES GP-FUEL INJECTIONS/N 50Y734-796; 66Z256-320
Group No: 7W-9745
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2B2695 | 1 BOLT (5/16-18X0.875-IN) | 2 | |
| 9M1974 | 2 WASHER-HARD (8.8X16X2-MM THK) | 3 | |
| 8N3529 | 3 PLUG-FUEL MANIFOLD | 4 | |
| 2M4453 | 4 SEAL-O-RING | 4 | |
| 7W2480 | 5 TUBE AS | 12 | |
| 8N8788 | 6 MANIFOLD-FUEL | 6 | |
| 8N8786 | 7 TUBE AS | 12 | |
| 7W2122 | 8 CONNECTOR-PORT | 24 | |
| 3J1907 | 9 SEAL-O-RING | 25 | |
| 9S4191 | 10 PLUG (9/16-18-THD) | 1 | |
| 3K0360 | 11 SEAL-O-RING | 1 | |
| 5P2645 | 12 ELBOW | 24 | |
| 3J7354 | 13 SEAL-O-RING | 25 | |
| 9S4182 | 14 PLUG (7/16-20-THD) | 1 | |
| 8N2755 | 15 CLAMP | 2 | |
| 0L2070 | 16 BOLT (3/8-16X2.25-IN) | 1 | |
| 7C2199 | 17 CLAMP | 2 | |
| 7C3036 | GROMMET | 1 | |
| 5M2894 | 18 WASHER-HARD (10.2X18.5X2.5-MM THK) | 4 | |
| 1N4639 | 19 TUBE AS | 1 | |
| 0T0065 | 20 BOLT (3/8-16X3.5-IN) | 1 | |
| 1W7534 | 21 ELBOW | 1 | |
| 1W7535 | 22 PLUNGER-VALVE | 1 | |
| 9N4053 | SPRING | 1 | |
| 2P7636 | 23 CONNECTOR (3/4-16 STR-THD) | 1 | |
| 0S1590 | 24 BOLT (3/8-16X2-IN) | 2 | |
| 8N6210 | 25 BRACKET-LINE SUPPORT | 1 | |
| 5P0537 | 26 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 6V4363 | 27 ELBOW | 1 | |
| 9M4584 | 28 CONNECTOR | 1 | |
| 0307949 | 29 ELBOW | 1 | |
| 2M9780 | 30 SEAL-O-RING | 4 | |
| 1W7533 | 31 ADAPTER-MANIFOLD | 1 | |
| 4B0831 | 32 BOLT (5/16-18X3.75-IN) | 1 | |
| 6B6205 | 33 SPACER (0.438X0.875X1.281-IN THK) | 1 | |
| 1W4499 | 34 PLATE | 2 | |
| 0S1614 | 35 BOLT (1/4-20X0.5-IN) | 4 | |
| 1W2565 | 36 CONNECTOR | 8 | |
| 2M4453 | 37 SEAL-O-RING | 24 | |
| 1W2566 | 38 CONNECTOR | 4 | |
| 1N4734 | 39 CLAMP | 14 | |
| 0L2070 | 40 BOLT (3/8-16X2.25-IN) | 5 | |
| 5M2894 | 41 WASHER-HARD (10.2X18.5X2.5-MM THK) | 11 | |
| 8N6327 | 42 TUBE AS | 1 | |
| 0307949 | 43 ELBOW | 2 | |
| 2M9780 | 44 SEAL-O-RING | 4 | |
| 8N6326 | 45 TUBE AS | 1 | |
| 2P1296 | 46 TEE | 1 | |
| 8N3928 | 47 ADAPTER-MANIFOLD | 1 | |
| 1D4539 | BOLT (5/16-18X2.5-IN) | 1 | |
| 9M1974 | 48 WASHER-HARD (8.8X16X2-MM THK) | 1 | |
| 7P8672 | 49 PLATE | 1 | |
| 0T0065 | 50 BOLT (3/8-16X3.5-IN) | 3 | |
| 9M4584 | 51 CONNECTOR | 1 | |
| 7K3377 | 52 PIPE | 3 | |
| 8N2755 | 53 CLAMP | 2 | |
| 1W7537 | 54 TUBE AS | 1 | |
| 8N8293 | 55 TUBE AS | 1 | |
| 1D4717 | 56 NUT (3/8-16-THD) | 1 | |
| 0S1594 | 57 BOLT (3/8-16X1-IN) | 2 | |
| 5P4900 | 58 ELBOW-FLARED | 1 | |
| 8N6211 | 59 PLATE-LINE SUPPORT | 1 |
