System And Components
5N-5757 PUMP GP-AUXILIARY SEA WATERPART OF 4W-6674 PUMP GP-AUXILIARY SEA WATER
Group No: 5N-5757
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5N9018 | 1 CLAMP AS | 2 | |
| 5N9013 | 2 SEAL-O-RING | 1 | |
| 5N9019 | 3 CLAMP AS | 1 | |
| 3N8444 | 4 THROWER-WATER | 1 | |
| 5N9023 | 5 BODY-DRIVE END | 1 | |
| 9M5082 | 6 STUD-TAPERLOCK | 4 | |
| 1D4718 | NUT-FULL (7/16-14-THD) | 4 | |
| 3H8027 | LOCK | 4 | |
| 3N8466 | 7 RING-RETAINING | 1 | |
| 3N8456 | 8 HOUSING-BEARING | 1 | |
| 3N8453 | 9 HOUSING-SEAL | 1 | |
| 0S1615 | 10 BOLT (1/4-20X0.75-IN) | 3 | |
| 7F2836 | LOCK | 3 | |
| 5N9020 | 11 SHAFT | 1 | |
| 8B7614 | 12 NUT-BEARING | 1 | |
| 8B7613 | LOCKNUT | 1 | |
| 3N8445 | 13 SPACER (40.041X47X12-MM THK) | 1 | |
| 3N8463 | 14 BEARING-ROLLER | 1 | |
| 4M6107 | 15 BEARING-INNER | 1 | |
| 8T0209 | RACE-ROLLER BEARING | 1 | |
| 5N2904 | 16 COLLAR-SEAL | 1 | |
| 5N2902 | 17 SEAL-OIL | 1 | |
| 5N9006 | 18 SEAL GP | 1 | |
| 5N9010 | 19 WASHER | 1 | |
| 5N9021 | 20 IMPELLER | 1 | |
| 5N9017 | 21 RING | 1 | |
| 5N9022 | 22 PLATE-PORT | 2 | |
| 5N9024 | 23 HOUSING (NON-DRIVE END) | 1 | |
| 3N8216 | 24 PLUG | 1 | |
| 3N8215 | WASHER | 1 | |
| 5N9015 | 25 SHIM (0.38-MM THK) | 2 | |
| 5N9016 | SHIM (0.25-MM THK) | 2 | |
| 7X3148 | 26 NUT-FULL | 1 | |
| 5N9014 | WASHER (25.5X44X4.3-MM THK) | 1 | |
| 5N9012 | PIN-COTTER | 1 | |
| 5N9009 | 27 KEY | 1 |
