7W-9746 LINES GP-FUEL INJECTIONS/N 29Z818-855; 72Z339-351

Group No: 7W-9746
Part NumberPart NameQty
2B26951 BOLT (5/16-18X0.875-IN)2
9M19742 WASHER-HARD (8.8X16X2-MM THK)3
8N35293 PLUG-FUEL MANIFOLD4
2M44534 SEAL-O-RING4
7W24805 TUBE AS16
8N87886 MANIFOLD-FUEL8
8N87867 TUBE AS16
7W21228 CONNECTOR-PORT32
3J19079 SEAL-O-RING33
9S419110 PLUG (9/16-18-THD)1
3K036011 SEAL-O-RING1
5P264512 ELBOW32
3J735413 SEAL-O-RING33
9S418214 PLUG (7/16-20-THD)1
1N473415 CLAMP2
0L207016 BOLT (3/8-16X2.25-IN)1
1W449917 PLATE2
5M289418 WASHER-HARD (10.2X18.5X2.5-MM THK)3
1N463919 TUBE AS1
0S161420 BOLT (1/4-20X0.5-IN)4
1W753421 ELBOW1
1W753522 PLUNGER-VALVE1
9N4053SPRING1
2P763623 CONNECTOR (3/4-16 STR-THD)1
0S159024 BOLT (3/8-16X2-IN)2
8N621025 BRACKET-LINE SUPPORT1
5P053726 WASHER-HARD (7.2X14.5X2-MM THK)4
6V436327 ELBOW1
9M458428 CONNECTOR1
030794929 ELBOW1
2M978030 SEAL-O-RING4
1W753331 ADAPTER-MANIFOLD1
4B083132 BOLT (5/16-18X3.75-IN)1
1W256533 CONNECTOR12
2M445334 SEAL-O-RING32
1W256635 CONNECTOR4
1N473436 CLAMP14
0L207037 BOLT (3/8-16X2.25-IN)5
5M289438 WASHER-HARD (10.2X18.5X2.5-MM THK)12
8N632739 TUBE AS1
030794940 ELBOW2
2M978041 SEAL-O-RING4
8N632642 TUBE AS1
2P129643 TEE1
8N392844 ADAPTER-MANIFOLD1
1D4539BOLT (5/16-18X2.5-IN)1
9M197445 WASHER-HARD (8.8X16X2-MM THK)1
7K337746 PIPE3
0T006547 BOLT (3/8-16X3.5-IN)4
9M458448 CONNECTOR1
6B620549 SPACER (0.438X0.875X1.281-IN THK)1
8N275550 CLAMP4
1W753751 TUBE AS1
8N829352 TUBE AS1
1D471753 NUT (3/8-16-THD)1
0S159454 BOLT (3/8-16X1-IN)2
5P490055 ELBOW-FLARED1
8N621156 PLATE-LINE SUPPORT1
7P867257 PLATE1
