6I-0059 GENERATOR GPS/N 3KJ1-UP

Group No: 6I-0059

Part Number	Part Name	Qty
4P3154	1 HEAT SINK	1
1181324	2 BRACKET-BEARING	1
4P3153	3 SPACER (20.6X77X27.8-MM THK)	1
1A9579	4 BOLT (5/16-18X1.5-IN)	4
4P3468	5 ROTOR-EXCITER	1
9Y0916	6 RECTIFIER AS	1
7E6573	7 COVER-DUST	1
4B0831	8 BOLT (5/16-18X3.75-IN)	4
9M1974	9 WASHER-HARD (8.8X16X2-MM THK)	8
9Y5817	10 STATOR-EXCITER	1
6I0088	11 COVER AS-EXCITER	1
5P0537	12 WASHER-HARD (7.2X14.5X2-MM THK)	15
9S8750	13 NUT-FULL (1/4-20-THD)	3
0S1614	14 BOLT (1/4-20X0.5-IN)	1
4P3149	15 PANEL-REAR	1
1496130	16 REGULATOR AS-VOLTAGE	1
7E6577	17 COVER-RECTIFIER	1
7C5709	18 SLEEVE	3
7C5708	19 GROMMET	3
0332075	20 WASHER (0.266X1.25X0.06-IN THK)	6
1N7219	21 CHANNEL-RUBBER	1
7E6578	22 PANEL	2
7E5940	23 FILM-INFORMATION (GENERATOR WIRING DIAGRAM)	1
7C5711	24 FILM-INSTRUCTION (VOLTAGE CONTROL ADJUSTMENT)	1
7E6575	25 PANEL AS	1
4F8711	PLUG-BUTTON	2
5N3174	PLUG-BUTTON	8
5N3175	PLUG-BUTTON	1
6K9593	PLUG-BUTTON	1
5M6214	26 PLUG (1/8-27 PTF)	2
7E6568	27 FRAME AS (RH)	1
7E6567	28 FRAME AS (LH)	1
4P3150	29 COVER AS	1
5N3167	SEAL-RING	3
5N3176	PLUG-BUTTON	3
6D7128	SEAL-O-RING	4
8P7065	PLUG-BUTTON	2
8T9587	SEAL-O-RING	2
0302284	PLUG-BUTTON	4
1116217	30 FAN-GENERATOR	1
5L2087	31 SPACER (9.25X13.72X50.8-MM THK)	4
1B2714	32 BOLT (1/4-20X2.5-IN)	4
7E1256	33 COVER-DRIP	1
4P3420	34 BRACKET (RH)	1
4P3419	35 BRACKET (LH)	1
5N3886	36 SCREW (10-32X1.5-IN)	2
9Y5820	37 SCREEN	1
4B2049	38 NUT (10-32-THD)	2
4P4527	39 ROTOR AS	1
1004891	40 STATOR AS	1
7E1257	41 DEFLECTOR-LOWER	1
9Y5821	42 DEFLECTOR	1
0S1615	43 BOLT (1/4-20X0.75-IN)	4
6I2737	44 RETAINER-BEARING	2
4W3901	KIT-ROTOR BALANCE WEIGHT (GENERATOR)	1
1004892	KIT-STATOR REWIND	1
7E7233	KIT-GENERATOR HARDWARE	1
