5N-8281 PANEL GP-INSTRUMENT24-32 VOLT. DUAL

Group No: 5N-8281
Part NumberPart NameQty
5L74371 SOCKET & WIRE8
5D00192 LAMP (24-VOLT)8
2W51113 AMMETER AS (60-AMPERE)2
6V3507SEAL-RECTANGULAR1
7W2731RETAINER1
6L20784 PLATE-FACE1
6L20775 FRAME AS1
7W20606 GAUGE (WATER TEMPERATURE)2
7W29377 GAUGE GP-ENGINE OIL PRESSURE2
7W30358 INDICATOR (TRANSMISSION OIL PRESSURE)2
5P34229 TEE-PIPE2
9G801010 SWITCH AS-PRESSURE (ENGINE OIL)2
6V8376SCREW-MACHINE (8-32X0.25-IN)2
9B7233LOCKWASHER2
5L744111 RESISTOR UNIT (65-OHM, 32-VOLT)6
4M531712 BUSHING-REDUCER4
6B507213 ADAPTER2
5L744214 SENDING UNIT (24-VOLT)2
9X112415 SENDER AS-PRESSURE (ENGINE OIL)2
4B2049NUT (10-32-THD)1
8T0328WASHER-HARD (5.5X10X1-MM THK)1
8F1434LOCKWASHER1
5L744716 SHUNT2
239733717 SENDER AS-PRESSURE (GEAR BOX OIL)2
2D732518 TEE-PIPE4
7W273119 RETAINER2
