System And Components
5N-2600 PUMP GP-AUXILIARY SEA WATERS/N 81Z5000-14500
Group No: 5N-2600
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 3N8468 | 1 CLAMP AS | 2 | |
| 3N8462 | 2 SEAL-O-RING | 1 | |
| 3N8469 | 3 CLAMP AS | 1 | |
| 1D4540 | BOLT (5/16-18X2.75-IN) | 2 | |
| 1D4716 | NUT-FULL (5/16-18-THD) | 2 | |
| 3N8444 | 4 THROWER-WATER | 1 | |
| 3N8447 | 5 BODY-DRIVE END | 1 | |
| 9M5082 | 6 STUD-TAPERLOCK | 4 | |
| 1D4718 | NUT-FULL (7/16-14-THD) | 4 | |
| 3H8027 | LOCK | 4 | |
| 3N8466 | 7 RING-RETAINING | 1 | |
| 3N8456 | 8 HOUSING-BEARING | 1 | |
| 3N8453 | 9 HOUSING-SEAL | 1 | |
| 0S1615 | 10 BOLT (1/4-20X0.75-IN) | 3 | |
| 7F2836 | LOCK | 3 | |
| 3N8451 | 11 SHAFT | 1 | |
| 8B7614 | 12 NUT-BEARING | 1 | |
| 8B7613 | LOCKNUT | 1 | |
| 3N8445 | 13 SPACER (40.041X47X12-MM THK) | 1 | |
| 3N8463 | 14 BEARING-ROLLER | 1 | |
| 3N8464 | 15 BEARING-ROLLER | 1 | |
| 5N2904 | 16 COLLAR-SEAL | 1 | |
| 5N2902 | 17 SEAL-OIL | 1 | |
| 3N8467 | 18 RING-CONTACT | 1 | |
| 3N8470 | SEAL-MECHANICAL | 1 | |
| 3N8442 | 19 SPACER-SPECIAL | 1 | |
| 5N2618 | 20 IMPELLER | 1 | |
| 3N8452 | 21 RING | 1 | |
| 5N4504 | 22 PLATE-PORT | 2 | |
| 3N8448 | 23 BODY-DRIVE END | 1 | |
| 3N8216 | 24 PLUG | 1 | |
| 3N8215 | WASHER | 1 | |
| 3N8441 | 25 SHIM (0.38-MM THK) | 2 | |
| 3N8455 | SHIM (0.25-MM THK) | 2 | |
| 3H1396 | 26 NUT-SLOTTED | 1 | |
| 3N8446 | WASHER (21X37X3.3-MM THK) | 1 | |
| 3B4621 | PIN-COTTER | 1 | |
| 5N4501 | 27 KEY | 1 |
