System And Components
7C-3613 PUMP GP-AUXILIARY SEA WATERS/N 81Z5000-14500
Group No: 7C-3613
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5N6055 | 1 SEAL GP | 1 | |
| 3N8448 | 2 BODY-DRIVE END | 1 | |
| 3N8444 | 3 THROWER-WATER | 1 | |
| 3N8447 | 4 BODY-DRIVE END | 1 | |
| 3N8468 | 5 CLAMP AS | 2 | |
| 1B9575 | BOLT (5/16-18X1.56-IN) | 2 | |
| 5S0003 | NUT (5/16-18-THD) | 2 | |
| 3H8027 | 6 LOCK | 4 | |
| 9M5082 | 7 STUD-TAPERLOCK | 4 | |
| 1D4718 | NUT-FULL (7/16-14-THD) | 4 | |
| 3N8466 | 8 RING-RETAINING | 1 | |
| 3N8456 | 9 HOUSING-BEARING | 1 | |
| 0S1615 | 10 BOLT (1/4-20X0.75-IN) | 3 | |
| 9L9588 | LOCK | 3 | |
| 7C3493 | 11 SHAFT | 1 | |
| 8B7614 | 12 NUT-BEARING | 1 | |
| 8B7613 | 13 LOCKNUT | 1 | |
| 3N8445 | 14 SPACER (40.041X47X12-MM THK) | 1 | |
| 3N8453 | 15 HOUSING-SEAL | 1 | |
| 3N8463 | 16 BEARING-ROLLER | 1 | |
| 3N8464 | 17 BEARING-ROLLER | 1 | |
| 5N2904 | 18 COLLAR-SEAL | 1 | |
| 5N2902 | 19 SEAL-OIL | 1 | |
| 3N8442 | 20 SPACER-SPECIAL | 1 | |
| 3N8462 | 21 SEAL-O-RING | 1 | |
| 3N8469 | 22 CLAMP AS | 1 | |
| 1D4540 | BOLT (5/16-18X2.75-IN) | 2 | |
| 1D4716 | NUT-FULL (5/16-18-THD) | 2 | |
| 3N8452 | 23 RING | 1 | |
| 3N8449 | 24 IMPELLER | 1 | |
| 3N8216 | 25 PLUG | 1 | |
| 3N8215 | WASHER | 1 | |
| 5N4504 | 26 PLATE-PORT | 2 | |
| 3N8441 | 27 SHIM (0.38-MM THK)(.38MM THK) | 2 | |
| 3N8455 | SHIM (0.25-MM THK)(.25MM THK) | 2 | |
| 8C0503 | 28 NUT-HEX SLOTTED | 1 | |
| 3N8446 | WASHER (21X37X3.3-MM THK) | 1 | |
| 5P8025 | 29 PIN-COTTER | 1 | |
| 5N4501 | 30 KEY | 1 |
