System And Components
122-0277 SENSOR & MOUNTING GP (CHG -02, -02D1)PEAK SENSOR CONTROL
Group No: 122-0277
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1199211 | 1 THERMOCOUPLE GP | 4 | |
| 4P0419 | 2 ADAPTER | 4 | |
| 8L4171 | 3 SENSOR GP-SPEED (ENGINE) | 3 | |
| 9W0532 | 4 SENSOR GP-TEMPERATURE | 1 | |
| 4G2544 | 5 CONNECTOR-PLUG | 1 | |
| 1220282 | 6 PLATE-MOUNTING | 1 | |
| 6K5967 | 7 CLIP | 2 | |
| 4S5719 | 8 SPACER (10.31X25X12.7-MM THK) | 1 | |
| 1220283 | 9 PLATE-MOUNTING | 1 | |
| 1638521 | 10 SENSOR GP-PRESSURE | 1 | |
| 1638521 | 10A SENSOR GP-PRESSURE (ENGINE OIL) | 1 | |
| 8T8732 | 11 RECEPTACLE-CONNECTOR (3-PIN) | 2 | |
| 3E6240 | 12 SWITCH AS-TEMPERATURE | 1 | |
| 3E3364 | RECEPTACLE (2-PIN) | 1 | |
| 3E3365 | WEDGE-RECEPTACLE LOCK (2-PIN) | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 3E3361 | 13 PLUG AS-CONNECTOR (2-PIN) | 1 | |
| 1028807 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 1028812 | SEAL | 1 | |
| 8L6557 | 14 CONNECTOR | 1 | |
| 5P1075 | 15 WASHER-HARD (10.2X22.5X3-MM THK) | 3 | |
| 1B4971 | 16 SPACER (0.406X1X1-IN THK) | 4 | |
| 3K6905 | 17 VALVE-BREATHER | 1 | |
| 6D3479 | 18 CLIP (LOOP) | 1 | |
| 0S1614 | 19 BOLT (1/4-20X0.5-IN) | 9 | |
| 6V7646 | 20 WASHER-HARD (7.2X25X2-MM THK) | 1 | |
| 9S8750 | 21 NUT-FULL (1/4-20-THD) | 5 | |
| 1090042 | 23 FILM-CONTACTOR | 1 | |
| 1210031 | 24 CONTACTOR-TEMPERATURE | 2 | |
| 1220287 | 25 HOSE AS | 1 | |
| 3N1968 | 26 MOUNT-FLEXIBLE | 4 | |
| 4W2648 | 27 ADAPTER AS | 4 | |
| 4F9325 | 28 GASKET | 4 | |
| 7C7332 | 29 FILM-CONTACTOR (SHUTOFF CRANKCASE PRESS HIGH) | 1 | |
| 7W3447 | 30 SPACER (10.2X19.05X10.2-MM THK) | 4 | |
| 7C5954 | 31 CONTACTOR-PRESSURE | 1 | |
| 1S2244 | 32 BOOT | 1 | |
| 1W0593 | 33 SUPPORT | 1 | |
| 1220288 | 34 HOSE AS | 1 | |
| 7X1043 | 35 SENSOR GP-TEMPERATURE (JACKET WATER) | 1 | |
| 7X1043 | 35A SENSOR GP-TEMPERATURE | 1 | |
| 8T8731 | 36 PLUG-CONNECTOR (3-PIN) | 2 | |
| 1238868 | 37 ADAPTER | 1 | |
| 6V5049 | 38 SEAL-O-RING | 3 | |
| 0307961 | 39 ELBOW | 4 | |
| 1220289 | 40 HOSE AS | 1 | |
| 1220290 | 41 HOSE AS | 1 | |
| 1220291 | 42 HOSE AS | 1 | |
| 7K9197 | 43 ELBOW | 5 | |
| 0S1591 | 44 BOLT (3/8-16X1.5-IN) | 1 | |
| 9S8752 | 45 NUT-FULL (3/8-16-THD) | 1 | |
| 6K4934 | 46 CLIP (SLOT) | 1 | |
| 6K4935 | 47 CLIP (TAB) | 1 | |
| 0S1590 | 48 BOLT (3/8-16X2-IN) | 2 | |
| 5R0939 | 49 CLIP (TAB) | 1 | |
| 5R0940 | 50 CLIP (SLOT) | 1 | |
| 5P0537 | 51 WASHER-HARD (7.2X14.5X2-MM THK) | 16 | |
| 0L1143 | 52 BOLT (3/8-16X2.5-IN) | 3 | |
| 3V3308 | 53 WASHER-HARD (10.2X20.5X2.5-MM THK) | 4 | |
| 6V8647 | 54 CONNECTOR | 1 | |
| 3J7354 | 55 SEAL-O-RING | 2 | |
| 8L2786 | 56 SEAL-O-RING | 2 | |
| 8T8729 | 57 PIN-CONNECTOR (16-GA TO 20-GA) | 6 | |
| 8T8730 | 58 SOCKET-CONNECTOR (16-GA TO 20-GA) | 6 | |
| 9X0435 | 59 CONNECTOR | 1 | |
| 5B3254 | 60 NUT-JAM (7/16-20-THD) | 4 | |
| 0S1616 | 61 BOLT (1/4-20X1-IN) | 4 | |
| 1638492 | SENSOR GP-PRESSURE (ATMOSPHERIC) | 2 |
