System And Components
5N-8282 PANEL GP-INSTRUMENT24-32 VOLT. SINGLE
Group No: 5N-8282
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7W2060 | 1 GAUGE (WATER TEMPERATURE) | 1 | |
| 2W5111 | 2 AMMETER AS (60-AMPERE) | 1 | |
| 6V3507 | SEAL-RECTANGULAR | 1 | |
| 7W2731 | RETAINER | 1 | |
| 5L7439 | 3 FRAME AS | 1 | |
| 5L7438 | 4 PLATE-FACE | 1 | |
| 7W2937 | 5 GAUGE GP-ENGINE OIL PRESSURE | 1 | |
| 7W3035 | 6 INDICATOR (TRANSMISSION OIL PRESSURE) | 1 | |
| 5L7437 | 7 SOCKET & WIRE | 4 | |
| 5D0019 | 8 LAMP (24-VOLT) | 4 | |
| 5L7441 | 9 RESISTOR UNIT (65-OHM, 32-VOLT) | 3 | |
| 5P3422 | 10 TEE-PIPE | 1 | |
| 4M5317 | 11 BUSHING-REDUCER | 2 | |
| 2D7325 | 12 TEE-PIPE | 2 | |
| 9G8010 | 13 SWITCH AS-PRESSURE (ENGINE OIL) | 1 | |
| 6V8376 | SCREW-MACHINE (8-32X0.25-IN) | 2 | |
| 9B7233 | LOCKWASHER | 2 | |
| 5L7442 | 14 SENDING UNIT (24-VOLT) | 1 | |
| 9X1124 | 15 SENDER AS-PRESSURE (ENGINE OIL) | 1 | |
| 4B2049 | NUT (10-32-THD) | 1 | |
| 8T0328 | WASHER-HARD (5.5X10X1-MM THK) | 1 | |
| 8F1434 | LOCKWASHER | 1 | |
| 2397337 | 16 SENDER AS-PRESSURE (GEAR BOX OIL) | 1 | |
| 5L7447 | 17 SHUNT | 1 | |
| 7W2731 | 18 RETAINER | 1 | |
| 6B5072 | 19 ADAPTER | 1 |
