System And Components
255-1656 LINES GP-PILOT -ALT PATTERN CONTROL, 4-WAYS/N DTG1-UP
Group No: 255-1656
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I0995 | 1 HOSE AS | 1 | |
| 4I3981 | 2 HOSE AS | 1 | |
| 4I6003 | 3 HOSE AS | 1 | |
| 4I8799 | 4 HOSE AS | 1 | |
| 4I9521 | 5 BAND-MARKER (RED, L1) | 4 | |
| 4I9522 | 6 BAND-MARKER (YELLOW, L2) | 4 | |
| 4I9523 | 7 BAND-MARKER (BLUE, L3) | 4 | |
| 4I9524 | 8 BAND-MARKER (BROWN, L4) | 4 | |
| 4I9525 | 9 BAND-MARKER (ORANGE, R1) | 4 | |
| 4I9526 | 10 BAND-MARKER (WHITE, R2) | 4 | |
| 4I9527 | 11 BAND-MARKER (GREEN, R3) | 4 | |
| 4I9528 | 12 BAND-MARKER (PURPLE, R4) | 4 | |
| 7K1181 | 13 STRAP-CABLE | 11 | |
| 7Y4173 | 14 HOSE AS | 1 | |
| 0875303 | 15 HOSE AS | 1 | |
| 1048768 | 16 HOSE AS | 1 | |
| 1048783 | 17 HOSE AS | 1 | |
| 1087203 | 18 HOSE AS | 5 | |
| 1241008 | 19 GUARD | 1 | |
| 1346918 | 20 HOSE AS | 1 | |
| 1659470 | 21 VALVE GP-SELECTOR (ALT PATTERN CONTROL, 4-WAY) | 1 | |
| 1764366 | 22 SUPPORT | 1 | |
| 1797616 | 23 HOSE AS | 1 | |
| 2181336 | 24 HOSE AS | 1 | |
| 2551671 | 25 GROMMET | 1 | |
| 1158645 | 26 GUARD | 2 | |
| 1488353 | 27 ELBOW AS | 6 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 1488378 | 28 ELBOW AS | 8 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1503036 | 29 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T1905 | ELBOW | 1 | |
| 1764684 | 30 SUPPORT | 1 | |
| 8T4121 | 31 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4191 | 32 BOLT (M10X1.5X16-MM) | 4 | |
| 8T4192 | 33 BOLT (M12X1.75X25-MM) | 4 | |
| 8T4223 | 34 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4224 | 35 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 8T4908 | 36 BOLT (M8X1.25X25-MM) | 2 |
