System And Components
9Q-5505 LINES GP-TRAVEL MOTORPART OF 9Q-5504 UNDERCARRIAGE AR
Group No: 9Q-5505
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 8T4121 | 1 WASHER-HARD (11X21X2.5MM THK) | 22 | |
| 5P1076 | 2 WASHER-HARD (13.5X30X4MM THK) | 2 | |
| 8T4223 | 3 WASHER-HARD (13.5X25.5X3MM THK) | 18 | |
| 1P3703 | 4 SEAL-RECTANGULAR (31.86MM ID) | 4 | |
| 1288993 | 5 TUBE AS | 1 | |
| 8T4648 | 6 BOLT (M12X1.75X70MM) | 2 | |
| 8T3957 | 7 BOLT-HEX SOCKET (M12X1.75X30MM) | 16 | |
| 8T4910 | 8 BOLT (M12X1.75X60MM) | 2 | |
| 7Y4800 | 9 SWIVEL GP | 1 | |
| 8T4136 | 10 BOLT (M10X1.5X25MM) | 6 | |
| 1288992 | 11 TUBE AS | 1 | |
| 0931296 | 12 CLAMP | 2 | |
| 3J1907 | 13 SEAL-O-RING (11.89MM ID) | 3 | |
| 6V8397 | 14 SEAL-O-RING (9.27MM ID) | 3 | |
| 1288991 | 15 TUBE AS | 1 | |
| 8T4956 | 16 BOLT (M12X1.75X35MM) | 16 | |
| 4I7745 | 17 CONNECTOR | 1 | |
| 3D2824 | 18 SEAL-O-RING (23.47MM ID) | 1 | |
| 6V8398 | 19 SEAL-O-RING (12.47MM ID) | 5 | |
| 1136685 | 20 HOSE AS | 2 | |
| 1288990 | 21 TUBE AS | 1 | |
| 6V8774 | 22 TEE | 1 | |
| 6V8724 | 23 ELBOW | 2 | |
| 3K0360 | 24 SEAL-O-RING (16.36MM ID) | 2 | |
| 6V8639 | 25 CONNECTOR | 2 | |
| 0960061 | 26 STRAP-CABLE | 5 | |
| 4I6003 | 27 HOSE AS | 2 | |
| 4I5546 | 28 SUPPORT | 1 | |
| 6V9844 | 29 TEE-SWIVEL | 1 | |
| 7I8294 | 30 TUBE AS | 1 | |
| 7I8296 | 31 TUBE AS | 1 | |
| 1P3704 | 32 SEAL-RECTANGULAR (38.2MM ID) | 8 | |
| 7I8293 | 33 TUBE AS | 1 | |
| 7I8295 | 34 TUBE AS | 1 | |
| 8T4196 | 35 BOLT (M10X1.50X35MM) | 16 |
