System And Components
230-0391 LINES GP-BOOMS/N ANB1-UP
Group No: 230-0391
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5I7223 | 1 TUBE AS | 1 | |
| 2300392 | 2 TUBE AS | 1 | |
| 2300393 | 3 TUBE AS | 1 | |
| 5I7229 | 4 TUBE AS | 2 | |
| 2300394 | 5 TUBE AS | 1 | |
| 5I7231 | 6 TUBE AS | 1 | |
| 7Y8036 | 7 HOSE AS | 2 | |
| 4I1676 | 8 CLIP | 12 | |
| 4I1674 | 9 CLIP | 12 | |
| 7Y4868 | 10 CLIP | 12 | |
| 4I8789 | 11 VALVE-CHECK | 1 | |
| 1488335 | 12 CONNECTOR AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8635 | CONNECTOR | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 6V9746 | 13 SEAL-O-RING | 2 | |
| 5K9090 | 14 SEAL-O-RING | 4 | |
| 7M8485 | 15 SEAL-O-RING | 1 | |
| 8T4139 | 16 BOLT (M12X1.75X30-MM) | 36 | |
| 8T4223 | 17 WASHER-HARD (13.5X25.5X3-MM THK) | 36 | |
| 1P3704 | 18 SEAL-RECTANGULAR | 1 | |
| 6I6721 | 19 ELBOW | 1 | |
| 8T4648 | 20 BOLT (M12X1.75X70-MM) | 4 |
