438-1293 PUMP GP-MAIN HYDRAULICS/N KBJ1-UP

Group No: 438-1293
Part NumberPart NameQty
4I10221 ORIFICE2
09639832 RING-RETAINING1
12978533 PLATE2
12978554 GASKET1
12978575 GASKET1
12978636 COVER1
12979217 RING-RETAINING2
12979278 BEARING2
15057829 COVER2
177247010 COVER1
177247111 COVER1
190489612 PLUG2
192057313 PIN-DOWEL4
200333414 COVER1
247892015 ORIFICE2
263747416 SET-BEARING2
273831517 SEAL-O-RING2
341283118 SHAFT-DRIVE1
341283419 SHAFT-DRIVEN1
341283920 GEAR (50-TEETH)2
341284021 CASE1
341284122 FLANGE1
341284223 BODY1
341284324 BLOCK-PORT1
341285725 GUIDE-BALL2
341285826 SPACER2
341286027 PUMP GP-GEAR1
341286228 SEAL-LIP TYPE1
423212329 BARREL AS-DRIVE1
423212830 BARREL AS-DRIVEN1
419841731 PISTON AS2
341287232 SPRING18
439600234 HEAD GP-PUMP (DRIVE)1
439602035 HEAD GP-PUMP (DRIVEN)1
094187536 DOWEL8
094188237 PLUG19
095092938 RING-RETAINING2
095094639 RING-RETAINING2
096394441 SEAL-O-RING1
129797942 DOWEL4
189976343 SEAL-O-RING8
193173644 SEAL-O-RING4
373951645 SWASHPLATE AS2
0941875DOWEL1
1733428BUSHING1
2426803PIN-DOWEL2
373951846 BEARING AS4
273831447 SEAL-O-RING1
3K036048 SEAL-O-RING2
7M848549 SEAL-O-RING2
7X255750 BOLT (M16X2X140-MM)1
8J464551 PLUG (STRAIGHT THREAD O-RING)2
8T413652 BOLT (M10X1.5X25-MM)20
8T413953 BOLT (M12X1.75X30-MM)10
8T414054 BOLT (M16X2X60-MM)4
8T417555 BOLT (M16X2X90-MM)2
8T417656 BOLT (M12X1.75X90-MM)2
8T419257 BOLT (M12X1.75X25-MM)10
8T419658 BOLT (M10X1.5X35-MM)2
9S418559 PLUG (3/4-16-THD)2
