System And Components
471-5245 LINES GP-RETURNS/N MBP1-UP
Group No: 471-5245 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1488436 | 1 TEE AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V8775 | TEE-FACE SEAL | 1 | |
| 7K1181 | 2 STRAP-CABLE | 6 | |
| 1653260 | 3 PIPE AS | 1 | |
| 1785908 | 4 HOSE AS | 1 | |
| 2827106 | 5 GROMMET | 2 | |
| 4533275 | 6 HOSE AS | 1 | |
| 4717656 | 7 HOSE AS | 1 | |
| 4873183 | 8 HOSE AS | 1 | |
| 1488340 | 9 CONNECTOR AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1488347 | 10 ELBOW AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488354 | 11 ELBOW AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V9002 | ELBOW | 1 | |
| 1488363 | 12 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9876 | ELBOW | 1 | |
| 1488372 | 13 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8721 | ELBOW | 1 | |
| 1488411 | 14 PLUG AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 1536237 | 15 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9004 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1671795 | 16 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 8T3491 | ELBOW | 1 | |
| 1725277 | 17 TEE AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 8T8901 | TEE-O-RING PORT | 1 | |
| 2735156 | 18 ADAPTER | 1 | |
| 2M9780 | 19 SEAL-O-RING | 1 | |
| 5P5148 | 20 STRAP-CABLE | 2 | |
| 5P7464 | 21 CLIP (SLOT) | 1 | |
| 5P7465 | 22 CLIP (TAB) | 1 | |
| 6J2680 | 23 SEAL-O-RING | 1 | |
| 8T2920 | 24 GROMMET (27-MM ID) | 1 | |
| 8T4139 | 25 BOLT (M12X1.75X30-MM) | 1 | |
| 8T4223 | 26 WASHER-HARD (13.5X25.5X3-MM THK) | 5 | |
| 8T4956 | 27 BOLT (M12X1.75X35-MM) | 4 |
