System And Components
419-8980 PUMP GP-FUEL TRANSFERS/N DTG1-UP
Group No: 419-8980
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7K1181 | 1 STRAP-CABLE | 1 | |
| 4447841 | 2 FILM-INSTRUCTION (REFUELING PUMP) | 1 | |
| 4186596 | 3 SWITCH AS-LIQUID LEVEL (FUEL TANK SHUTOFF) | 1 | |
| 2S4078 | SEAL-O-RING | 1 | |
| 8T8729 | PIN-CONNECTOR (16-GA TO 20-GA) | 2 | |
| 2434505 | RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 3245761 | 4 COVER AS | 1 | |
| 1211029 | CLIP | 1 | |
| 3685216 | 5 PUMP GP-FUEL TRANSFER | 1 | |
| 5014186 | 6 VALVE GP-REFUELING (FOOT) | 1 | |
| 3685219 | 7 CONNECTOR-HOSE | 1 | |
| 4382674 | 8 SUPPORT AS | 1 | |
| 1358572 | 9 BOLT AS | 2 | |
| 1358573 | 10 BOLT AS | 4 | |
| 8T4194 | 11 BOLT (M12X1.75X50-MM) | 2 | |
| 8T4223 | 12 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4244 | 13 NUT (M12X1.75-THD) | 2 | |
| 9M7958 | 14 CLAMP-HOSE | 4 | |
| 4571157 | 15 HOSE (430-CM) | ||
| 4571157 | 15A HOSE (38-CM) |
