System And Components
236-6320 PUMP GP-REFUELINGS/N MSD1-UP
Group No: 236-6320
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5C6108 | 1 SWITCH GP-REFUELING (FUEL TANK SHUTOFF) | 1 | |
| 9M7958 | 2 CLAMP-HOSE | 4 | |
| 1205114 | 3 FILM-INSTRUCTION (REFUELING PUMP) | 1 | |
| 1224021 | 4 COVER | 1 | |
| 1358572 | 5 BOLT AS | 2 | |
| 1358573 | 6 BOLT AS | 4 | |
| 2291859 | 7 PUMP & MOTOR GP-REFUELING | 1 | |
| 2291860 | 8 VALVE AS (FOOT) | 1 | |
| 2291861 | 9 CONNECTOR-HOSE | 1 | |
| 4382674 | 10 SUPPORT AS | 1 | |
| 2S1647 | 11 GROMMET | 1 | |
| 8T4194 | 12 BOLT (M12X1.75X50-MM) | 2 | |
| 8T4223 | 13 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4244 | 14 NUT (M12X1.75-THD) | 2 | |
| 3666495 | 15 HOSE (430-CM) | ||
| 3666495 | 15A HOSE (61-CM) |
