237-1283 LINES GP-AIR CONDITIONER -HYDRAULIC CAB RISERS/N JJM1-UP

Group No: 237-1283
Part NumberPart NameQty
7K11811 STRAP-CABLE2
12296052 TUBE4
12296573 CLAMP2
13002524 HOSE-DRAIN2
23588915 PLATE1
23590146 CLAMP-SPRING10
23590157 HOSE2
32103368 HOSE AS1
1217136SEAL-O-RING2
25730709 HOSE AS1
1961665SWITCH AS-PRESSURE (REFRIGERANT)1
1217138SEAL-O-RING2
115864510 GUARD1
1S099411 CLIP (LOOP)1
6D164112 CLIP8
6V326513 CLIP1
6V735714 BOLT (M6X1X25-MM)1
7Y816915 GROMMET2
8T412117 WASHER-HARD (11X21X2.5-MM THK)6
8T413618 BOLT (M10X1.5X25-MM)3
8T413719 BOLT (M10X1.5X20-MM)3
9X825620 WASHER (6.6X12X2-MM THK)1
5P076721 HOSE (381-CM)
5P076721A HOSE (389-CM)
305044122 BAND-MARKER (HS)2
305044223 BAND-MARKER (HR)2
