System And Components
112-5702 VALVE GP-PILOT MANIFOLDS/N 6TL1-257
Group No: 112-5702
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1230153 | 1 VALVE GP-RELIEF (AUXILIARY) | 1 | |
| 1230154 | 2 VALVE GP-FLOW CONTROL | 1 | |
| 1230155 | 3 VALVE GP-SOLENOID | 4 | |
| 1230156 | 4 VALVE GP-SOLENOID | 2 | |
| 1230157 | 5 SPRING GP | 1 | |
| 1230368 | 5A ROD-THREADED | 1 | |
| 5W9420 | 5B LOCKNUT (M8X1.25-THD) | 1 | |
| 5P3108 | 5C SEAL-O-RING | 1 | |
| 1230161 | 6 PISTON | 1 | |
| 1230168 | 7 SPRING GP | 1 | |
| 1230369 | 7A SPRING | 1 | |
| 1230370 | 7B RETAINER | 1 | |
| 1230371 | 7C RETAINER | 1 | |
| 1230170 | 8 BODY GP-VALVE | 1 | |
| 1230171 | 9 BODY GP-VALVE | 1 | |
| 1230172 | 10 PLATE AS | 1 | |
| 1230173 | 11 PLUG | 1 | |
| 1230174 | 12 BODY GP-VALVE | 1 | |
| 1230175 | 13 BODY | 1 | |
| 1230176 | 14 SLEEVE | 1 | |
| 1230177 | 15 FILTER GP-OIL | 1 | |
| 8U6310 | 16 ROD-THREADED | 2 | |
| 1230179 | 17 VALVE GP-CHECK | 1 | |
| 1218112 | SEAL-O-RING | 1 | |
| 1097293 | 18 FILTER ELEMENT-OIL (STANDARD EFFICIENCY) | 1 | |
| 9S8005 | 19 PLUG (3/4-16-THD) | 2 | |
| 8T2396 | 20 BOLT (M6X1X60-MM) | 2 | |
| 6V5683 | 21 BOLT (M6X1X16-MM) | 2 | |
| 8T6699 | 22 BOLT-SOCKET HEAD (M5X0.8X35-MM) | 4 | |
| 6V8397 | 23 SEAL-O-RING | 4 | |
| 9X7454 | 24 SEAL-O-RING | 1 | |
| 3K0360 | 25 SEAL-O-RING | 2 | |
| 6V8225 | 26 NUT (M6X1-THD) | 2 |
