Assembly
100%

244-8481 PUMP GP-PISTONS/N BKM1-UP; BLP1-UP

Group No: 244-8481
Part NumberPart NameQty
4I10221 ORIFICE2
7Y42152 SPACER2
09639833 RING-RETAINING1
09643894 SPRING18
12620165 PUMP GP-GEAR (PILOT)1
9T0835RING-RETAINING1
12978536 PLATE2
34128407 CASE1
12978558 GASKET1
12978579 GASKET1
129786310 COVER1
129792111 RING-RETAINING2
341286212 SEAL-LIP TYPE1
129792713 BEARING2
129797914 DOWEL4
150578215 COVER2
173342716 GUIDE-BALL2
177247017 COVER1
177247118 COVER1
177256819 ACTUATOR GP-PUMP (DRIVE)1
177256920 ACTUATOR GP-PUMP (DRIVEN)1
273831421 SEAL-O-RING1
179976322 FLANGE1
188421023 PISTON AS2
192057324 PIN-DOWEL4
263747425 SET-BEARING2
194837126 BARREL AS (DRIVE)1
194837427 BARREL AS (DRIVEN)1
341283128 SHAFT-DRIVE1
341283429 SHAFT-DRIVEN1
200333330 HEAD-PUMP1
200333431 COVER1
373951632 SWASHPLATE AS2
0941875DOWEL1
1733428BUSHING1
2426803PIN-DOWEL2
373951833 BEARING AS4
8T419634 BOLT (M10X1.5X35-MM)2
247878235 BODY1
247892036 ORIFICE2
094187537 DOWEL6
094188238 PLUG16
095094639 RING-RETAINING2
9S418540 PLUG (3/4-16-THD)2
096394441 SEAL-O-RING1
189976342 SEAL-O-RING8
190489643 PLUG2
193173644 SEAL-O-RING4
3K036045 SEAL-O-RING2
7M848546 SEAL-O-RING2
7X255747 BOLT (M16X2X140-MM)1
8J464548 PLUG (STRAIGHT THREAD O-RING)2
273831549 SEAL-O-RING2
8T413650 BOLT (M10X1.5X25-MM)20
8T413952 BOLT (M12X1.75X30-MM)10
8T414053 BOLT (M16X2X60-MM)4
8T417554 BOLT (M16X2X90-MM)2
8T417655 BOLT (M12X1.75X90-MM)2
8T419256 BOLT (M12X1.75X25-MM)10
095092957 RING-RETAINING2
341283960 GEAR (50-TEETH)2
2502503KIT-SEAL (PILOT GEAR PUMP)1
