Assembly
100%

188-4937 PUMP GP-FUEL TRANSFERS/N BDK288-2000

Group No: 188-4937
Part NumberPart NameQty
4I84431 VALVE-CHECK (FUEL TRANSFER PUMP)1
8U08762 HOSE GP-REFUELING1
11384913 FUSE (15-AMPERE)(FUEL TRANSFER PUMP)1
13794384 ELBOW1
17548075 PUMP & MOTOR GP (FUEL TRANSFER)1
1028802KIT-RECEPTACLE (2-PIN)1
3E3365WEDGE-RECEPTACLE LOCK (2-PIN)1
9W0852PIN-CONNECTOR (14-GA TO 16-GA)2
19656506 SWITCH AS (REFUELING PUMP RELAY)(REFUELING PUMP)1
1976076NUT (M30X1-THD)1
1976082BOOT1
19686437 SWITCH AS-MAGNETIC (24-VOLT)(REFUELING PUMP RELAY)1
20721598 ELBOW1
20816589 FILM-INSTRUCTION (REFUELING)1
235172810 PLATE1
244858611 COUPLING1
244858712 COVER1
244953013 FITTING1
245257914 ADAPTER1
2M978015 SEAL-O-RING1
5C726116 NUT (M8X1.25-THD)2
5W513117 GROMMET1
8T422418 WASHER-HARD (8.8X16X2-MM THK)2
8T751419 SCREW-HEX SOCKET (M8X1.25X30-MM)2
8T940220 CLAMP-HOSE2
120972921 HOSE (100-CM)
207514122 SEAL
0960061STRAP-CABLE3
1973800LOOM
