System And Components
186-0485 BOX GP-JUNCTIONS/N BDK1-252; BDK254-254
Group No: 186-0485
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 5W1125 | 1 SOCKET | 4 | |
| 5W1291 | 2 NUT | 4 | |
| 1046692 | 3 RECEPTACLE AS-CONNECTOR (2-PIN) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 2 | |
| 1138490 | 4 FUSE (10-AMPERE) | 4 | |
| 1138491 | 5 FUSE (15-AMPERE) | 8 | |
| 1138492 | 6 FUSE (20-AMPERE) | 2 | |
| 1138493 | 7 FUSE (25-AMPERE) | 2 | |
| 1174861 | 8 RELAY AS (WIPER CUT-OUT) | 1 | |
| 1174861 | 8A RELAY AS (HYDRAULIC LOCKOUT) | 1 | |
| 1174861 | 8B RELAY AS (HORN) | 1 | |
| 1412759 | 9 FUSE (5-AMPERE) | 14 | |
| 1554574 | 10 RELAY AS (INTERVAL WIPER) | 1 | |
| 1955658 | 11 HARNESS AS-BOX | 1 | |
| 1028806 | KIT-RECEPTACLE (8-PIN) | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 1552255 | KIT-CONNECTING PLUG (12-PIN) | 2 | |
| 1552265 | KIT-CONNECTING PLUG (8-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 | |
| 1552271 | KIT-CONNECTING PLUG (4-PIN) | 1 | |
| 1963537 | 12 BOX AS | 1 | |
| 1968643 | 13 SWITCH AS-MAGNETIC (24-VOLT)(MAIN POWER RELAY) | 1 | |
| 1968643 | 13A SWITCH AS-MAGNETIC (24-VOLT)(FUEL PUMP RELAY) | 1 | |
| 1973528 | 14 COVER AS | 1 | |
| 5W1123 | FASTENER | 4 | |
| 5W1124 | WASHER-RETAINING | 4 | |
| 6V0292 | PLUG | 1 | |
| 1281423 | SEAL (23CM) | ||
| 2047685 | 15 SWITCH AS-MAGNETIC (FLASHER RELAY) | 1 | |
| 2140864 | 16 RECEPTACLE AS (4-PIN) | 1 | |
| 1028801 | KIT-RECEPTACLE (12-PIN) | 1 | |
| 8T8737 | PLUG-SEAL | 4 | |
| 2172956 | 17 PLATE | 1 | |
| 0960061 | 18 STRAP-CABLE | 4 | |
| 4P8134 | 19 CLIP (LADDER) | 2 | |
| 5C2874 | 20 NUT (M5X0.8-THD) | 1 | |
| 5P4116 | 21 WASHER-HARD (8.8X20.5X2-MM THK) | 1 | |
| 8T0288 | 22 BOLT (M5X0.8X12-MM) | 5 | |
| 8T3016 | 23 WASHER (5.3X10X1-MM THK) | 5 | |
| 8T4121 | 24 WASHER-HARD (11X21X2.5-MM THK) | 4 | |
| 8T4136 | 25 BOLT (M10X1.5X25-MM) | 4 | |
| 8T4200 | 26 BOLT (M8X1.25X16-MM) | 1 | |
| 1281423 | 27 SEAL (67CM) |
