System And Components
212-5368 LINES GP-TRAVEL MOTORS/N B4N1-UP
Group No: 212-5368
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I6003 | 1 HOSE AS | 2 | |
| 7K1181 | 2 STRAP-CABLE | 6 | |
| 1136479 | 3 FLANGE-SPECIAL | 2 | |
| 1158728 | 4 GROMMET | 4 | |
| 1192395 | 5 HOSE AS | 2 | |
| 1645552 | 6 CONNECTOR AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 1875884 | 7 HOSE AS | 2 | |
| 2048075 | 8 HOSE AS | 1 | |
| 2048083 | 9 HOSE AS | 1 | |
| 2048087 | 10 HOSE AS | 1 | |
| 2048143 | 11 HOSE AS | 1 | |
| 2125462 | 12 TUBE AS | 1 | |
| 2125463 | 13 TUBE AS | 1 | |
| 2125464 | 14 TUBE AS | 2 | |
| 2181199 | 15 HOSE AS | 2 | |
| 1017404 | 16 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 16 | |
| 1488336 | 17 CONNECTOR AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488364 | 18 ELBOW AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 1488367 | 19 ELBOW AS | 2 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 1488439 | 20 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8774 | TEE | 1 | |
| 1504037 | 21 TEE AS | 1 | |
| 6V8398 | SEAL-O-RING | 2 | |
| 6V9844 | TEE-SWIVEL | 1 | |
| 1597841 | 22 SWIVEL GP | 1 | |
| 1P3703 | 23 SEAL-RECTANGULAR | 16 | |
| 4I5546 | 24 SUPPORT | 1 | |
| 4J5267 | 25 SEAL-O-RING | 4 | |
| 5K9090 | 26 SEAL-O-RING | 4 | |
| 5P1076 | 27 WASHER-HARD (13.5X30X4-MM THK) | 2 | |
| 6V0400 | 28 FLANGE-HALF | 24 | |
| 7Y3730 | 29 FLANGE-SPECIAL | 2 | |
| 8T4121 | 30 WASHER-HARD (11X21X2.5-MM THK) | 6 | |
| 8T4136 | 31 BOLT (M10X1.5X25-MM) | 6 | |
| 8T4139 | 32 BOLT (M12X1.75X30-MM) | 16 | |
| 8T4184 | 33 BOLT (M12X1.75X45-MM) | 32 | |
| 8T4194 | 34 BOLT (M12X1.75X50-MM) | 16 | |
| 8T4223 | 35 WASHER-HARD (13.5X25.5X3-MM THK) | 64 | |
| 8T4648 | 36 BOLT (M12X1.75X70-MM) | 2 | |
| 1U8846 | 37 SEALANT-GASKET (2ML) |
