System And Components
218-0995 LINES GP-PILOT -BOOM FLOATS/N JLC1-UP; JLD1-UP
Group No: 218-0995
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1992002 | 1 SUPPORT AS | 1 | |
| 2101312 | 2 HOSE AS | 1 | |
| 1031396 | 3 HOSE AS | 1 | |
| 4I6054 | 4 HOSE AS | 1 | |
| 1048777 | 5 HOSE AS | 1 | |
| 1488439 | 6 TEE AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V8774 | TEE | 1 | |
| 1027685 | 7 HOSE AS | 1 | |
| 4I0800 | 8 HOSE AS | 1 | |
| 7Y4384 | 9 HOSE AS | 1 | |
| 1735144 | 10 HOSE AS | 1 | |
| 1488378 | 11 ELBOW AS | 3 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 4I1694 | 12 CONNECTOR | 1 | |
| 1992004 | 13 BRACKET | 1 | |
| 3J1907 | 14 SEAL-O-RING | 1 | |
| 1673466 | 15 SWITCH AS-PRESSURE (BOOM FLOAT) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 9X3401 | PIN-CONNECTOR (16-GA TO 18-GA) | 2 | |
| 1261767 | PIN-CONNECTOR (14-GA TO 16-GA) | 2 | |
| 4I9527 | 16 BAND-MARKER (GREEN, R3) | 2 | |
| 7K1181 | 17 STRAP-CABLE | 21 | |
| 8T4908 | 18 BOLT (M8X1.25X25-MM) | 2 | |
| 1850472 | 19 VALVE GP-SOLENOID (BOOM FLOAT) | 1 | |
| 5C9553 | 20 BOLT (M6X1X16-MM) | 2 | |
| 9X8256 | 21 WASHER (6.6X12X2-MM THK) | 2 | |
| 8T4224 | 22 WASHER-HARD (8.8X16X2-MM THK) | 2 | |
| 1488407 | 23 PLUG AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1488363 | 24 ELBOW AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9876 | ELBOW | 1 | |
| 1488325 | 25 CONNECTOR AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8641 | CONNECTOR | 1 | |
| 1110985 | 26 HOSE AS | 1 | |
| 1488413 | 27 REDUCER AS | 1 | |
| 4J5477 | SEAL-O-RING | 1 | |
| 6V8934 | ADAPTER | 1 | |
| 1504027 | 28 TEE AS | 1 | |
| 3E2310 | TEE | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1645629 | 29 FITTING AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 1087516 | FITTING | 1 | |
| 2019236 | 30 VALVE GP-FLOW CONTROL (BOOM FLOAT, PILOT OIL) | 1 | |
| 1646874 | 31 FITTING AS-ELBOW (QUICK DISCONNECT, MALE) | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 0857356 | FITTING | 1 | |
| 2023762 | 32 HOSE AS | 1 | |
| 1488434 | 33 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9843 | TEE | 1 | |
| 1488367 | 34 ELBOW AS | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9850 | ELBOW | 1 | |
| 1503056 | 35 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 3 | |
| 6V8788 | TEE | 1 | |
| 1488433 | 36 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9836 | TEE-SWIVEL | 1 |
