System And Components
264-0216 WIRING GP-QUICK COUPLERS/N JCD1-UP; JNK1-UP
Group No: 264-0216
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2635758 | 1 HARNESS AS-WIRING (QUICK COUPLER VALVE) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 2 | |
| 7X2619 | 2 BOLT (M6X1X10-MM) | 4 | |
| 1552715 | 3 SWITCH AS-ROTARY (QUICK COUPLER) | 1 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 1863735 | PIN-CONNECTOR (16-GA TO 18-GA) | 4 | |
| 9X8256 | 4 WASHER (6.6X12X2-MM THK) | 4 | |
| 2074765 | 5 BRACKET AS | 1 | |
| 1613128 | 6 RELAY (24-VOLT)(QUICK COUPLER LEVER, PRIORITY) | 1 | |
| 1613128 | 6A RELAY (24-VOLT)(QUICK CPLR LEVER, ON POSITION) | 1 | |
| 1613128 | 6B RELAY (24-VOLT)(QUICK CPLR, LOCK POSITION) | 2 | |
| 6V8369 | 7 NUT (7/16-28-THD) | 1 | |
| 2H3920 | 8 LOCKWASHER | 1 | |
| 1584212 | 9 FILM-INSTRUCTION (QUICK COUPLER) | 1 | |
| 1340394 | 10 KNOB-CONTROL | 1 | |
| 1134683 | 11 ALARM AS (QUICK COUPLER) | 1 | |
| 8T0328 | 12 WASHER-HARD (5.5X10X1-MM THK) | 1 | |
| 8T0325 | 13 BOLT (M5X0.8X14-MM) | 1 | |
| 1554572 | 14 HARNESS AS-WIRING (QUICK COUPLER ALARM) | 1 | |
| 1028802 | KIT-RECEPTACLE (2-PIN) | 1 | |
| 3S2093 | 15 STRAP-CABLE | 2 | |
| 1858636 | 16 COVER | 1 | |
| 2067599 | 17 HARNESS AS-WIRING (QUICK COUPLER LOCKOUT) | 1 | |
| 1028804 | KIT-RECEPTACLE (4-PIN) | 1 | |
| 1552270 | KIT-CONNECTING PLUG (2-PIN) | 1 |
