System And Components
142-7704 LINES GP-FRONTS/N SBN1-849; RAW1-547
Group No: 142-7704
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 1876710 | 1 HOSE AS | 1 | |
| 1241047 | 2 HOSE AS | 4 | |
| 1653185 | 3 HOSE AS | 1 | |
| 1P3703 | 4 SEAL-RECTANGULAR | 6 | |
| 1940174 | 5 HOSE GP-HYDRAULIC | 1 | |
| 1940177 | 6 HOSE GP-HYDRAULIC (CONTROL VALVE, STICK) | 1 | |
| 4I1674 | 7 CLIP | 2 | |
| 4J5267 | 8 SEAL-O-RING | 6 | |
| 5K9090 | 9 SEAL-O-RING | 1 | |
| 1940180 | 10 HOSE GP-HYDRAULIC | 1 | |
| 2144511 | 11 FITTING GP-HYDRAULIC (4-BOLT FLANGE) | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V8635 | CONNECTOR | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 1588160 | 12 VALVE GP-LOAD CONTROL (STICK CYLINDER)(STICK CYLINDER) | 1 | |
| 1427769 | 13 TUBE AS | 1 | |
| 6V9746 | 14 SEAL-O-RING | 4 | |
| 1427768 | 15 TUBE AS | 1 | |
| 1241062 | 16 SUPPORT AS | 1 | |
| 8T4192 | 17 BOLT (M12X1.75X25-MM) | 2 | |
| 8T4223 | 18 WASHER-HARD (13.5X25.5X3-MM THK) | 10 | |
| 1335828 | 19 SUPPORT AS | 1 | |
| 1087550 | 20 CLIP | 1 | |
| 8T4910 | 21 BOLT (M12X1.75X60-MM) | 2 | |
| 8T4186 | 22 BOLT (M10X1.5X40-MM) | 4 | |
| 9F2167 | 23 SCREW-PURGE (3/8-24X1.164-IN) | 1 | |
| 8T4121 | 24 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 9X6032 | 25 BOLT-SOCKET HEAD (M10X1.5X30-MM) | 30 | |
| 8T5005 | 26 BOLT (M10X1.5X70-MM) | 2 | |
| 8T4184 | 27 BOLT (M12X1.75X45-MM) | 4 | |
| 6V0400 | 28 FLANGE-HALF | 2 | |
| 2363212 | 29 HOSE GP-HYDRAULIC | 1 | |
| 8T4172 | 30 BOLT (M10X1.5X80-MM) | 2 | |
| 1588117 | 31 VALVE GP-LOAD CONTROL (BOOM CYLINDER)(BOOM CYLINDER) | 1 | |
| 4J5268 | 32 SEAL-O-RING | 1 | |
| 2363213 | 33 HOSE GP-HYDRAULIC | 1 | |
| 3E8028 | 35 BOLT-SOCKET HEAD (M10X1.5X150-MM) | 6 | |
| 8T4139 | 36 BOLT (M12X1.75X30-MM) | 2 |
