Assembly
100%

245-3661 HEAD GP-MOTORS/N H2C1-99999

Group No: 245-3661
Part NumberPart NameQty
24536641 VALVE GP-MOTOR CONTROL (PRESSURE, FLOW COMPENSATOR)1
24536652 VALVE GP-MOTOR CONTROL (TRAVEL)1
24536663 HEAD1
12498814 PISTON1
12498825 TRUNNION1
13574546 PISTON1
12498847 PIN-THREADED1
24280048 GUIDE-VALVE2
12357869 VALVE2
123578710 SEAT2
6V820111 BOLT-SOCKET HEAD (M16X2X45-MM)8
107311612 SEAL-O-RING2
9X768013 SEAL-O-RING4
033603914 SEAL-O-RING2
242026215 RING-BACKUP2
125220516 BOLT-SHALLOW HEAD (M14X1.5X25-MM)1
135745517 SEAL3
7X290618 PIN2
120439419 PLUG-BREAK OFF1
123201720 PLUG-BREAK OFF1
123580021 PLUG AS2
190865722 VALVE GP-RELIEF (CROSSOVER, MAKEUP)2
2170288CAP1
1908718KIT-SEAL (RELIEF VALVE)1
