System And Components
241-8691 HEAD GP-MOTOR -WINCH, HOOKS/N BXL1-454
Group No: 241-8691
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2419058 | 1 VALVE GP-FLOW CONTROL (WINCH, HOOK) | 1 | |
| 1908657 | 2 VALVE GP-RELIEF (CROSSOVER, MAKEUP)(WINCH, HOOK) | 2 | |
| 2428004 | 3 GUIDE-VALVE | 2 | |
| 1249881 | 4 PISTON | 1 | |
| 1249882 | 5 TRUNNION | 1 | |
| 1357454 | 6 PISTON | 1 | |
| 1249884 | 7 PIN-THREADED | 1 | |
| 2420262 | 8 RING-BACKUP | 2 | |
| 9S8004 | 9 PLUG (9/16-18-THD) | 1 | |
| 3J1907 | 10 SEAL-O-RING | 1 | |
| 6V8201 | 11 BOLT-SOCKET HEAD (M16X2X45-MM) | 8 | |
| 1073116 | 12 SEAL-O-RING | 2 | |
| 9X7680 | 13 SEAL-O-RING | 3 | |
| 0336039 | 14 SEAL-O-RING | 2 | |
| 1252205 | 15 BOLT-SHALLOW HEAD (M14X1.5X25-MM) | 1 | |
| 1357455 | 16 SEAL | 3 | |
| 7X2906 | 17 PIN | 2 | |
| 1204394 | 18 PLUG-BREAK OFF | 1 | |
| 1232017 | 19 PLUG-BREAK OFF | 1 | |
| 6V8351 | 20 SEAL-O-RING | 1 | |
| 1235800 | 21 PLUG AS | 2 | |
| 6V8200 | 22 BOLT-SOCKET HEAD (M12X1.75X35-MM) | 4 | |
| 1235799 | 23 SEAT | 1 | |
| 1421412 | 24 VALVE | 1 | |
| 1235798 | 25 SEAT | 1 | |
| 4J0522 | 26 SEAL-O-RING | 1 | |
| 1342652 | 27 BODY | 1 | |
| 1953836 | 28 SETSCREW (M10X1X10-MM) | 1 | |
| 1235786 | 29 VALVE | 2 | |
| 1235787 | 30 SEAT | 2 |
