System And Components
225-4575 CYLINDER GP-STICKS/N SRC1-UP
Group No: 225-4575
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 7Y4660 | 1 HEAD | 1 | |
| 7Y4669 | 2 RING-BACKUP | 1 | |
| 7Y4672 | 3 RING-RETAINING | 1 | |
| 7Y4695 | 4 LOCKNUT (M80X2-THD) | 1 | |
| 9X3601 | 5 SEAL AS | 1 | |
| 1884217 | 6 RING | 2 | |
| 1884218 | 7 RING | 1 | |
| 2344509 | 8 CYLINDER AS | 1 | |
| 2357770 | 8A BUSHING | 1 | |
| 2426833 | 9 RING-SEAL | 1 | |
| 2667839 | 10 ROD AS | 1 | |
| 2357770 | 10A BUSHING | 1 | |
| 1659290 | 11 SEAL-LIP TYPE | 1 | |
| 1709864 | 12 SEAL-U-CUP | 1 | |
| 1884216 | 13 PISTON | 1 | |
| 0950929 | 14 RING-RETAINING | 2 | |
| 0951633 | 15 SEAL-O-RING | 1 | |
| 1038378 | 16 RING-RETAINING | 1 | |
| 1038379 | 17 RING | 1 | |
| 1038380 | 18 STOP | 1 | |
| 1140760 | 19 BUSHING | 1 | |
| 1289265 | 20 SEAL-BUFFER | 1 | |
| 7Y4673 | 21 RING-BACKUP | 1 | |
| 7Y4918 | 22 STOP | 1 | |
| 7Y5215 | 23 BOLT-SOCKET HEAD (M24X3X90-MM) | 8 | |
| 2426840 | KIT-SEAL (STICK CYLINDER) | 1 |
