System And Components
451-5232 FILTER & LINES GP-HYDRAULICS/N XAA1-UP; YCA1-UP
Group No: 451-5232 · Commonality
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I9527 | 1 BAND-MARKER (GREEN, R3) | 2 | |
| 7K1181 | 2 STRAP-CABLE | 1 | |
| 1319453 | 3 HOSE AS | 1 | |
| 1319588 | 4 HOSE AS | 1 | |
| 1588987 | 5 FILTER & VALVE GP-PILOT (HYDRAULIC OIL) | 1 | |
| 1710098 | 6 VALVE GP-CHECK | 1 | |
| 2076553 | 7 FLANGE | 1 | |
| 2144513 | 8 FITTING GP-HYDRAULIC | 1 | |
| 2898194 | 9 FILTER GP-OIL (HYDRAULIC, CASE DRAIN) | 1 | |
| 3075097 | 10 TEE AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 3075098 | ADAPTER-TEE | 1 | |
| 3713049 | 11 HOSE AS | 1 | |
| 4526934 | 12 HOSE AS | 1 | |
| 4538729 | 13 SUPPORT | 1 | |
| 4661934 | 14 HOSE AS | 1 | |
| 0951706 | 15 SEAL-O-RING | 1 | |
| 1081781 | 16 BOLT-SOCKET HEAD (M12X1.75X35-MM) | 4 | |
| 1488340 | 17 CONNECTOR AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8639 | CONNECTOR | 1 | |
| 1488347 | 18 ELBOW AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1488357 | 19 ELBOW AS | 1 | |
| 5K9090 | SEAL-O-RING | 1 | |
| 6V9008 | ELBOW (90-DEG) | 1 | |
| 7M8485 | SEAL-O-RING | 1 | |
| 1488364 | 20 ELBOW AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8625 | ELBOW | 1 | |
| 1488372 | 21 ELBOW AS | 1 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8398 | SEAL-O-RING | 1 | |
| 6V8721 | ELBOW | 1 | |
| 1488407 | 22 PLUG AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 9S4191 | PLUG (9/16-18-THD) | 1 | |
| 1488411 | 23 PLUG AS | 2 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 1645567 | 24 COUPLER AS-QUICK DISCONNECT (MALE) | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 2147568 | SEAL-O-RING | 1 | |
| 1645590 | 25 VALVE AS-FLUID SAMPLING | 1 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 8C3446 | VALVE-SAMPLING | 1 | |
| 4J0527 | 26 SEAL-O-RING | 1 | |
| 6V0852 | 27 CAP-DUST | 1 | |
| 8C3451 | 28 CAP-DUST (HYDRAULIC OIL) | 1 | |
| 8T4121 | 29 WASHER-HARD (11X21X2.5-MM THK) | 3 | |
| 8T4136 | 30 BOLT (M10X1.5X25-MM) | 3 | |
| 8T4192 | 31 BOLT (M12X1.75X25-MM) | 2 | |
| 8T4223 | 32 WASHER-HARD (13.5X25.5X3-MM THK) | 6 | |
| 8T4224 | 33 WASHER-HARD (8.8X16X2-MM THK) | 4 | |
| 8T4908 | 34 BOLT (M8X1.25X25-MM) | 4 | |
| 8T5041 | 35 BOLT (M12X1.75X120-MM) | 4 |
