Assembly
100%

242-6487 LINES GP-AUXILIARY HYDRAULIC -STICK, HIGH PRESSURES/N MDE1-UP; JGZ1-UP

Group No: 242-6487
Part NumberPart NameQty
5I85101 HOSE AS1
17379162 CLAMP-HALF4
25364453 HOSE AS1
25364534 TUBE AS1
25364545 TUBE AS1
27709546 VALVE GP-MANUAL2
1P37037 SEAL-RECTANGULAR3
1P37048 SEAL-RECTANGULAR3
1P57679 FLANGE-HALF4
6V040010 FLANGE-HALF4
7Y453811 CLAMP-HALF4
8T412112 WASHER-HARD (11X21X2.5-MM THK)4
8T413913 BOLT (M12X1.75X30-MM)8
8T418314 BOLT (M12X1.75X40-MM)4
8T418415 BOLT (M12X1.75X45-MM)8
8T419416 BOLT (M12X1.75X50-MM)8
8T422317 WASHER-HARD (13.5X25.5X3-MM THK)24
8T495618 BOLT (M12X1.75X35-MM)4
8T668519 BOLT (M10X1.5X110-MM)4
