System And Components
255-1796 LINES GP-BOOM CYLINDER -LOWERING CONTROLS/N T2S1-UP
Group No: 255-1796
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I1674 | 1 CLIP | 4 | |
| 7K1181 | 2 STRAP-CABLE | 18 | |
| 1132798 | 3 HOSE AS | 2 | |
| 1192325 | 4 SUPPORT AS | 2 | |
| 1488347 | 5 ELBOW AS | 1 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V9007 | ELBOW | 1 | |
| 6V9746 | SEAL-O-RING | 1 | |
| 1491738 | 6 CLIP | 4 | |
| 1503058 | 7 TEE AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 8C8431 | TEE | 1 | |
| 2254785 | 8 VALVE GP-LOAD CONTROL (BOOM CYLINDER) | 2 | |
| 2391579 | 9 HOSE AS | 2 | |
| 2455122 | 10 BLOCK | 1 | |
| 2551629 | 11 HOSE AS | 2 | |
| 2551998 | 12 SUPPORT AS | 1 | |
| 2608017 | 13 HOSE AS | 2 | |
| 2700024 | 14 TUBE AS | 1 | |
| 2700025 | 15 TUBE AS | 1 | |
| 2700028 | 16 TUBE AS | 1 | |
| 2700030 | 17 TUBE AS | 1 | |
| 2724504 | 18 BLOCK | 1 | |
| 2724505 | 19 SUPPORT AS | 2 | |
| 1488336 | 20 CONNECTOR AS | 6 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8636 | CONNECTOR | 1 | |
| 1488341 | 21 CONNECTOR AS | 2 | |
| 3D2824 | SEAL-O-RING | 1 | |
| 6V8713 | CONNECTOR | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488353 | 22 ELBOW AS | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9001 | ELBOW | 1 | |
| 1488361 | 23 ELBOW AS (90-DEG) | 2 | |
| 3J7354 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V9200 | ELBOW | 1 | |
| 1488378 | 24 ELBOW AS | 4 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488390 | 25 ELBOW AS | 2 | |
| 2M9780 | SEAL-O-RING | 1 | |
| 6V8626 | ELBOW | 1 | |
| 7J9108 | SEAL-O-RING | 1 | |
| 1488411 | 26 PLUG AS | 1 | |
| 3K0360 | SEAL-O-RING | 1 | |
| 9S4185 | PLUG (3/4-16-THD) | 1 | |
| 1P3703 | 27 SEAL-RECTANGULAR | 4 | |
| 2802747 | 28 BOLT-SOCKET HEAD (M10X1.5X60-MM) | 8 | |
| 4I9521 | 29 BAND-MARKER (RED, L1) | 2 | |
| 4I9522 | 30 BAND-MARKER (YELLOW, L2) | 2 | |
| 4I9525 | 31 BAND-MARKER (ORANGE, R1) | 2 | |
| 4I9526 | 32 BAND-MARKER (WHITE, R2) | 2 | |
| 6V9746 | 33 SEAL-O-RING | 2 | |
| 7J9108 | 34 SEAL-O-RING | 2 | |
| 8T4121 | 35 WASHER-HARD (11X21X2.5-MM THK) | 18 | |
| 8T4139 | 36 BOLT (M12X1.75X30-MM) | 4 | |
| 8T4186 | 37 BOLT (M10X1.5X40-MM) | 2 | |
| 8T4196 | 38 BOLT (M10X1.5X35-MM) | 8 | |
| 8T4223 | 39 WASHER-HARD (13.5X25.5X3-MM THK) | 12 | |
| 8T4956 | 40 BOLT (M12X1.75X35-MM) | 8 | |
| 8T6466 | 41 BOLT (M10X1.5X60-MM) | 8 |
