System And Components
260-7971 LINES GP-PILOT -SYSTEM 1, 1-WAY, 1-PUMPS/N DHK1-UP; CXY1-UP
Group No: 260-7971
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 4I9523 | 1 BAND-MARKER (BLUE, L3) | 4 | |
| 4I9524 | 2 BAND-MARKER (BROWN, L4) | 2 | |
| 4I9527 | 3 BAND-MARKER (GREEN, R3) | 8 | |
| 5I4396 | 4 HOSE AS | 1 | |
| 7K1181 | 5 STRAP-CABLE | 13 | |
| 7Y4399 | 6 HOSE AS | 1 | |
| 1087375 | 7 HOSE AS | 1 | |
| 1110988 | 8 HOSE AS | 1 | |
| 1360207 | 9 STRAP-CABLE (BLACK) | 2 | |
| 2661108 | 10 SUPPORT AS | 1 | |
| 2661133 | 11 HOSE AS | 1 | |
| 2661136 | 12 HOSE AS | 1 | |
| 2661139 | 13 HOSE AS | 1 | |
| 2966975 | 14 HOSE AS | 1 | |
| 1241008 | 15 GUARD | 1 | |
| 1488338 | 16 CONNECTOR AS | 4 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T0075 | CONNECTOR | 1 | |
| 1488378 | 17 ELBOW AS | 5 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 6V8724 | ELBOW | 1 | |
| 1488433 | 18 TEE AS | 1 | |
| 6V8397 | SEAL-O-RING | 2 | |
| 6V9836 | TEE-SWIVEL | 1 | |
| 1503036 | 19 ELBOW AS | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 8T1905 | ELBOW | 1 | |
| 1504027 | 20 TEE AS | 2 | |
| 3E2310 | TEE | 1 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V8397 | SEAL-O-RING | 1 | |
| 1645567 | 21 COUPLER AS-QUICK DISCONNECT (MALE) | 2 | |
| 3J1907 | SEAL-O-RING | 1 | |
| 6V3965 | FITTING (QUICK DISCONNECT) | 1 | |
| 1710188 | 22 VALVE GP-SOLENOID (NEG FLOW CONT, PROPN RED VALVE) | 1 | |
| 6V0852 | 23 CAP-DUST | 2 | |
| 6V9829 | 24 CAP (ORFS) | 1 | |
| 8T4177 | 25 BOLT (M8X1.25X90-MM) | 4 | |
| 8T4192 | 26 BOLT (M12X1.75X25-MM) | 4 | |
| 8T4223 | 27 WASHER-HARD (13.5X25.5X3-MM THK) | 4 | |
| 8T4224 | 28 WASHER-HARD (8.8X16X2-MM THK) | 4 |
