System And Components
334-1075 DOOR GP-CABS/N JKR1-UP
Group No: 334-1075
| Part Number | Part Name | Qty | |
|---|---|---|---|
| 2A6397 | 1 STRAP | 2 | |
| 6G9485 | 2 LEVER | 1 | |
| 6V8073 | 3 LINK-CONNECTING | 1 | |
| 8T3504 | 4 HANDLE AS-INSIDE | 1 | |
| 8Y6359 | 5 HANDLE AS | 1 | |
| 8Y4501 | SPRING-HANDLE | 1 | |
| 9X2546 | 6 BOLT (M6X1X20-MM) | 2 | |
| 0909555 | 7 CLIP | 2 | |
| 0909554 | 8 STUD-BALL | 2 | |
| 1444107 | 9 FASTENER | 2 | |
| 1915077 | 10 STRAP | 4 | |
| 2474330 | 11 PLATE | 1 | |
| 2474332 | 12 PLATE | 1 | |
| 2474333 | 13 PLATE | 1 | |
| 3609597 | 14 STRIKER AS | 1 | |
| 2633954 | 15 STRUT | 1 | |
| 2821960 | 16 HINGE | 1 | |
| 2822154 | 17 BRACKET AS | 1 | |
| 2822160 | 18 BRACKET AS | 1 | |
| 2823007 | 19 SCREW-FLAT HEAD (M8X1.25X30-MM) | 18 | |
| 2938877 | 20 SEAL | 1 | |
| 2938878 | 21 SEAL | 1 | |
| 2938879 | 22 SEAL | 1 | |
| 3341080 | 23 DOOR AS-CAB | 1 | |
| 3341087 | 24 PLATE | 1 | |
| 3341088 | 25 PLATE | 1 | |
| 3341090 | 26 COVER | 1 | |
| 3341153 | 27 LATCH-DOOR | 1 | |
| 3341154 | 28 LINK AS | 1 | |
| 6V8185 | NUT (1/4-20-THD) | 1 | |
| 1085471 | CLEVIS | 1 | |
| 3E4352 | 29 WASHER-HARD (8.8X20.5X2.5-MM THK) | 12 | |
| 3E4353 | 30 WASHER-HARD (11X25X3-MM THK) | 2 | |
| 9X2616 | 31 SCREW-SOCKET (M8X1.25X16-MM) | 5 | |
| 6V2687 | 32 SCREW-PAN HEAD (10-24X1-IN) | 4 | |
| 6V7357 | 33 BOLT (M6X1X25-MM) | 4 | |
| 6V7636 | 34 PIN AS-SPRING | 4 | |
| 6V8225 | 35 NUT (M6X1-THD) | 2 | |
| 8T4189 | 36 BOLT (M8X1.25X20-MM) | 4 | |
| 8T4195 | 37 BOLT (M10X1.5X30-MM) | 2 | |
| 8T4205 | 38 WASHER-HARD (7.2X14.5X2-MM THK) | 4 | |
| 8T7547 | 39 BOLT (M8X1.25X30-MM) | 8 | |
| 8Y4614 | 40 SEAL-HANDLE | 1 | |
| 9X8256 | 41 WASHER (6.6X12X2-MM THK) | 2 | |
| 1788894 | 42 SEAL (418-CM) | ||
| 3S2093 | 43 STRAP-CABLE | 4 |
